on networks N150 User Manual

3
Router Description
Front Panel. The front panel has five status LEDs.
Power/Test LED. If solid green, the router is
ready. If blinking green, the router is
performing the power-on diagnostic test. If off,
the router is not connected to a power source.
Wireless LED. If solid green, the wireless
connection is established. If blinking green,
data is being transmitted. If off, the wireless
interface is turned off.
Internet LED. If solid green, the router is
linked to the Internet. If blinking green, data is
being transmitted. If off, no Ethernet cable is
connected from the Internet port to the
modem.
Two Ethernet LEDs. If one of these LEDs is
off, make sure the Ethernet cable is securely
attached at both ends, and that the computer
is turned on. If solid green, the local port is
connected to an Ethernet device. If blinking
green, data is being transmitted. If off, no
Ethernet device is connected to the port.

on networks N150 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Bandwidth	2.4 GHz
Rack mounting	No
USB ports quantity	0
Minimum system requirements	Microsoft Internet Explorer 5.0 / Firefox 2.0 / Safari 1.4
Compatible operating systems	Microsoft Windows 7, XP, Vista, 2000, \\r Mac OS, \\r UNIX, \\r Linux
Ethernet LAN (RJ-45) ports	3
DHCP client	-
Security algorithms	WEP, WPA, WPA2-PSK
Product color	White
LED indicators	LAN, Power, WAN, WLAN
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	90.7 mm
Width	76.4 mm
Height	160 mm
Weight	190 g
