on networks N300RE Installation Guide

3
Install the Extender
Place the extender and connect it to your WiFi network.
Place the Extender and Plug It In
1 Place the extender halfway between your router and the location
that has poor WiFi coverage.
DO DON’T
Tip: If you have to use a different location, move the extender closer
to the location with poor coverage, but still within the wireless
range of the router.
2 Plug
the extender into a power outlet and wait 1 minute until the
extender starts.
The Status LED
lights green.

on networks N300RE Specifications

General

Type	-
Maximum transfer distance	- m
Windows operating systems supported	Yes
Product color	White
Bandwidth	2.4 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	WPS
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wi-Fi data rate (max)	300 Mbit/s
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	45 mm
Width	74 mm
Height	112 mm
Weight	245 g
