One Control Crocodile Tail Loop User Manual

 In this example you can see that the echo unit in Loop 8 is connected via the S8 (Send 8) and R8
(Return 8) sockets, unlike Loops 1 thru 7 which are all internally connected, Loops 8 Thru 10 are not
and must be linked together using the Out and In sockets from each loop to run the signal into the next
loop.
 The output of Loop 8 in this example is being used as the main out to run to the amplifier input, if you
needed to use more loops for effects in the second section of loops (8, 9, 10) then simply connect the
output from the previous loop into the input of the next loop. For example if you desired to run a reverb
unit in loop 9 you would need to link the out socket of Loop 8 to the input socket of loop 9, Loop 9 Out
would then become your main output.
SETUP 2
PAGE 2
