21b, right
21b, right
21b, left
21b, left
B x 2
C x 4
STEP 16
Attach two inner drawer rollers (21b), one left and one
right, to the bottom of drawer using four screws (C) as shown.
Make sure rollers are oriented to the back of the drawer.
Refer to drawing below for which holes in the roller to use.
STEP 15
Attach drawer handle (F) to drawer front using
two screws (B).
STEP 17
Attach two inner drawer rollers (21b), one left and one right,
to the bottom of the keyboard tray (7) using four screws (C).
THIRD TO
LAST HOLE
THIRD
HOLE
7
ASSEMBLY INSTRUCTIONS
14 of 16
B
F
C x 4
To Next Page
