Onicon F-4300 Installation Hardware Instruction

F-4300 Clamp-on Ultrasonic Thermal Energy Measurement System
Installation Hardware Instruction for Clamp-on Thermowells
ON I CON
Flow and Energy Measurement
DOC-0004103 Rev.A
ONICON Incorporated • 11451 Belcher Road South • Largo, FL 33773 • USA • www.onicon.com
Directions for Installation:
1. Remove junction box cover and set aside.
2. Attach the provided Velcro or the enclosure mounting hardware in the desired location as
shown below.
JUNCTION BOX COVER
PROVIDED VELCRO
