ADJUSTMENT MANUAL -- 14DELITE/21DELITE(FLAT) PAL, STEREO, SINGLE AV
EEPROM MEMORY SETTINGS
SERVICE MENU SETTINGS
PARAMETE
R
V
alue Remark
s
1] VCJ ADJ. (ADJUSTMENT ON LINE)
1: RF DLY 32 (ADJ) RF AGC ADJUSTMEN
T
2: VIF VCO 26 (FIX) AUTO VIF VCO ALIGN
3: STRAP 8 (FIX) AUTO SOUND TRAP ALIGN
4: SECAM BLK :
R
32 NOT AVAILABLE FOR M6126
4
5: SECAM BLK : B 32 NOT AVAILABLE FOR M6126
4
2] RASTER ADJ (ADJUSTMENT ON LINE)
1: VPOS 1 (ADJ) VERTICAL POSITION 50/60Hz
2: V-SIZ 40 (ADJ) VERTICAL HEIGHT 50Hz/60H
z
3: HC50 6 (ADJ) HOR CENTRE IN RF
4: HC60 9 (ADJ) HOR CENTRE IN NTSC
5: W-BAC
K
0 (FIX) WHITE BACK 1: SOAKING
6: VS-CO
R
42 (ADJ) VERTICAL S CORRECTION
7: V-LN 28 (ADJ) VERTICAL LINEARIT
Y
3] CRT ADJ (ADJUSTMENT ON LINE)
1: C
R
127 (ADJ) CUT OFF RED
2: CG 127 (ADJ) CUT OFF GREEN
3: CB 127 (ADJ) CUT OFF BLUE
4: GR 63 (ADJ) DRIVE RE
D
5: GB 63 (ADJ) DRIVE BLUE
6: C RC 32 NOT AVAILABLE FOR M6126
4
7: C GC 32 NOT AVAILABLE FOR M6126
4
4] PICTURE ADJ (ADJUSTMENT ON LINE)
1: SUB BRI 90 (ADJ) SUB BRIGHTNESS
2: SUB CON 10 (ADJ) SUB CONTRAS
T
5] SVC MENU (FIXED ADJUSTMENT)
1: HVCO 3 (FIX) AUTO HOR VCO ALIGN
2: C-TRAP 2 (FIX) CHROMA TRAP FINE
3: S.TINT 50 (FIX) RF SUB TINT
4: S.TINTAV 50 (FIX) NTSC SUB TINT 4.43/3.57MHz
5: S.TINTYUV 32 NOT AVAILABLE FOR M6126
4
6: S.COL 17 (FIX) SUB COLOUR
7: C.ANGLE9
5
0 (FIX) FOR NTSC ANGLE
1: OSDLVL 1 (FIX) OSD LEVEL
2: Y-DL 4 (FIX) Y- DELAY
3: Y-DLSCM 10 NOT AVAILABLE FOR M6126
4
4: SCM KILLER 1 NOT AVAILABLE FOR M6126
4
5: SCMBGP 3 NOT AVAILABLE FOR M6126
4
6: VID.OUTGAIN 7 (FIX) VIDEO OUT GAIN
7: OM DET 0 (FIX) OVER MOD. DETECTION
1: S.SLICE DN 2 (FIX) SYNC SLICING
2: A.SLICEDN 1 (FIX) AUTO SYNC SLICING
3: V.SYNCDET 0 (FIX) VERTICAL SYNC DETECT
4: V.1WIN 0 (FIX) WINDOW FOR V-SYNC
5: AFC1GUP 0 (FIX)
6: AFC2GDN 0 (FIX)
