CONTENTS
Page Nos.
1 Features of Delite 14" (36 cm) &
Flat Delite 21" (51 cm) 2
2. Pre Installation 3
3. Remote & TV Controls 4
4. Installation 5
5. Viewing A Television Program 7
6. Picture Menu 8
7. Sound Menu 9
8. Channel Scheduler 10
9. Feature Menu 12
10. Features On Remote 15
11. Safety Instruction 17
12. Trouble Shooting 18
13. Warranty 19
14. Specifications 20
1
14. SPECIFICATIONS
• Type : Colour Television Receiver
• Receiving System : PAL - BG or
PAL - BG/I or
PAL - BG/H, SECAM - BG/DK/K1
NTSC Playback (IN AV MODE)
• Colour System : Phase Alternation by Line (PAL)
NTSC Playback (IN VIDEO MODE)
• Channel Coverage : VHF(Low) : Channel2 to 4
VHF(High) : Channel5 to 12
UHF : Channel 21 to 69
CATV(Middle) : X-Z+2S1-S10
CATV(Super) : S11-S20
CATV(Hyper) : S21-S41
• Aerial Input Impedance : 75 ohms unbalanced
• Power input
Rated Voltage : 230V AC, 50 Hz
• A/V Terminal connections
Line Input – Video : 1 Vp-p, 75 ohms (RCA Pin Jack)
– Audio : 500 mV rms (-4dBs) High
impedance RCA Pin Jack
Line Output – Video : 1 Vp-p, 75 ohms (RCA Pin Jack)
– Audio : 500 mV rms (-4 dBs) High
impedance RCA Pin Jack
• Power Consumption 110 W 65 W
• Picture Tube 21” 14”
(measured diagonally) (53 cm) (36 cm)
• Audio output
W PMPO 250 120
• Dimensions
Width (mm) 620 475
Depth (mm) 495 379
Height (mm) 449 319
• Weight (Approx.) 26 kg. 11 kg.
Flat Delite 21” Delite 14”
•Accessories : Remote control,
AA size Dry cell battery x 2 Units
Design & Specifications subject to change without notice
