14
Speaker Package
For detailed information, see the pages in parentheses.
■ Front
■ Rear
a STANDBY/ON indicator
With the Auto Standby function, the SKW-570
automatically turns on when an input signal is
detected in Standby mode. When there’s no input
signal for a while, the SKW-570 automatically
enters Standby mode.
b OUTPUT LEVEL control (44)
This control is used to adjust the volume of the
subwoofer.
c LINE INPUT (20)
This RCA input should be connected to the
subwoofer pre out on the AV receiver with supplied
RCA cable.
Note:
The Auto Standby function turns the subwoofer on when
the input signal exceeds a certain level. If the Auto
Standby function does not work reliably, try slightly
increasing or decreasing the subwoofer output level on
the AV receiver (page 72).
Subwoofer (SKW-570)
a
bc
To AC outlet
Red: Subwoofer in standby mode
Blue: Subwoofer on
HT-S5200_En.book 14 ページ ２００９年３月９日 月曜日 午後４時３１分
