Onkyo BD-SP809 - Page 65

2011/07/05 1-15-2 E5WF0EL.fm
AUDIO CBA
POWER ASSEMBLY
POWER SUPPLY CBA
L4002 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
L4003 INDUCTOR(0.47µH K) LAP02TAR47K LLAXKATTUR47
L4306 WIRE CP STP-S-0.60 XZ40F0REN002
TRANSISTOR
Q4003 NPN TRANSISTOR SMD MMBTSC3875G NQ1GBTSC3875
RESISTORS
R4043 CHIP RES. 1/10W J 2k Ω RRXAJR5Z0202
R4044 CHIP RES.(1608) 1/10W F 75 Ω RRXAFR5Z0750
R4045 CHIP RES.(1608) 1/10W F 75 Ω RRXAFR5Z0750
R4046 CHIP RES.(1608) 1/10W F 75 Ω RRXAFR5Z0750
R4047 CHIP RES.(1608) 1/10W F 75 Ω RRXAFR5Z0750
R4048 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R4049 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R4050 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R4051 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R4052 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R4053 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R4054 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R4055 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R4056 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R4057 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
MISCELLANEOUS
JK4000 RCA JACK MSP-251V-10 GILT LF JXRL010LY143
JK4001 RCA JACK(YELLOW) MSD-251V-11 GILT FE JXRL010LY110
JK4002 RCA JACK 1PIN(GREEN) MSP-251V-16-
GILT(B11
JXRL010LY178
JK4003 RCA JACK 1PIN(BLUE) MSP-251V-31-GILT(B11 JXRL010LY179
JK4004 RCA JACK 1PIN(RED) MSP-251V-12-GILT(B11 JXRL010LY176
JK4005 FIBER OPTIC TRANS.MODULE 0C-0805T*002 JWHHA00JD002
JP4001 WIRE CP STP-S-0.60 XZ40F0REN002
Ref. No. Description Part No.
AUDIO CBA
Consists of the following:
----------
CAPACITORS
C2273 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2274 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2275 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2276 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2277 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2278 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2279 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2280 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2281 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2282 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
CONNECTORS
CN2001 FFC CONNECTOR IMSA-9615S-17A-PP-A JC96J17ER007
CN2002 FFC CONNECTOR IMSA-9615S-17A-PP-A JC96J17ER007
CN2201 FFC CONNECTOR 21PIN IMSA-9615S-21A-
PP-A
JC96J21ER007
RESISTORS
R2235 CHIP RES. 1/10W F 470 Ω RRXAFR5H4700
R2236 CHIP RES. 1/10W F 470 Ω RRXAFR5H4700
R2237 CHIP RES. 1/10W F 470 Ω RRXAFR5H4700
R2238 CHIP RES. 1/10W F 470 Ω RRXAFR5H4700
R2239 CHIP RES. 1/10W F 470 Ω RRXAFR5H4700
R2240 CHIP RES. 1/10W F 470 Ω RRXAFR5H4700
R2241 CHIP RES. 1/10W F 470 Ω RRXAFR5H4700
R2242 CHIP RES. 1/10W F 470 Ω RRXAFR5H4700
R2243 CHIP RES. 1/10W F 470 Ω RRXAFR5H4700
R2244 CHIP RES. 1/10W F 470 Ω RRXAFR5H4700
Ref. No. Description Part No.
R2246 CHIP RES. 1/10W F 5.6k Ω RRXAFR5H5601
R2247 CHIP RES. 1/10W F 5.6k Ω RRXAFR5H5601
R2248 CHIP RES. 1/10W F 5.6k Ω RRXAFR5H5601
R2249 CHIP RES. 1/10W F 5.6k Ω RRXAFR5H5601
R2250 CHIP RES. 1/10W F 5.6k Ω RRXAFR5H5601
R2251 CHIP RES. 1/10W F 5.6k Ω RRXAFR5H5601
R2252 CHIP RES. 1/10W F 5.6k Ω RRXAFR5H5601
R2253 CHIP RES. 1/10W F 5.6k Ω RRXAFR5H5601
R2254 CHIP RES. 1/10W F 5.6k Ω RRXAFR5H5601
R2255 CHIP RES. 1/10W F 5.6k Ω RRXAFR5H5601
MISCELLANEOUS
JK2200 RCA JACK 1PIN(WHITE) MSP-251V-13-
GILT(B11
JXRL010LY177
JK2201 RCA JACK 1PIN(RED) MSP-251V-12-GILT(B11 JXRL010LY176
JK2202 RCA JACK 6PIN MSD-246V-184-GILT(B1 JXRL060LY181
JK2203 RCA JACK 2PIN MSD-242V-03-GILT(B11 JXRL020LY180
Ref. No. Description Part No.
POWER ASSEMBLY
Consists of the following:
1VSA28208
POWER SUPPLY CBA
RS232C CBA
----------
----------
Ref. No. Description Part No.
POWER SUPPLY CBA
Consists of the following:
----------
CAPACITORS
C1001 ELECTROLYTIC CAP. 10µF/50V M(105C) CE1JMASTH100
C1002# CAP METALIZED FILM 0.068µF/275V/K/MPX CTA683SER002
C1004 ELECTROLYTIC CAP. 47µF/25V/M CED47RENW016
C1005 CHIP CERAMIC CAP.(1608) B K 0.1µF/25V CHD1EK30B104
C1006 CHIP CERAMIC CAP.(1608) B K 0.1µF/25V CHD1EK30B104
C1008 CAP ELE STD-105 220µF/200V/M/105 CE2DMZPTH221
C1010 METALIZED FILM CAP. 0.010µF/400V K CMK103EUR002
C1011 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1012 CHIP CERAMIC CAP.(1608) B K 0.1µF/25V CHD1EK30B104
C1013# CAP METALIZED FILM 0.022µF/275V/K/MPX CTA223SER002
C1018 ALUMINUM_ELECTROLYTIC_CAP 4700µF/
16V/M(105C)
CE1CMZPTH472
C1024 ELECTROLYTIC CAP. 470µF/16V/M CEC471ENW016
C1025 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1026 CERAMIC CAP. B K 220pF/500V CCD2JKS0B221
C1029 ELECTROLYTIC CAP. 220µF/16V M(105C) CE1CMASTH221
C1030 CERAMIC CAP. SL J 100pF/1KV CCD3AJPSL101
C1033 ELECTROLYTIC CAP. 33µF/50V/M(105C) CE1JMASTH330
C1034 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1040# SAFETY CAP. 2200pF/250V CCG2EMA0E222
C1041# SAFETY CAP. 2200pF/250V CCG2EMA0E222
CONNECTORS
CN1000# CONNECTOR PRINT OSU B2P3-VH-B
(LF)(SN)
J3VH030JG014
CN1004 FFC CONNECTOR IMSA-9615S-23A-PP-A JC96J23ER007
DIODES
D1001 DIODE 1N5397-B NDLZ001N5397
D1002 DIODE 1N5397-B NDLZ001N5397
D1003 DIODE 1N5397-B NDLZ001N5397
D1004 DIODE 1N5397-B NDLZ001N5397
D1006 DIODE FR154 NDLZ000FR154
D1007 RECTIFIER DIODE BA157 NDQZ000BA157
D1008 DIODE ZENER 27BSB-T26 NDTB027BST26
Ref. No. Description Part No.
