DR-UN7
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
EXPLODED VIEW PARTS LIS
T
<Notes>
<MDD1N> : USA model
<MDS4N> : South American model
<MGQ3P> : Hongkong model
<MDT3N> : Taiwanese model
<MGT3P> : Southeast agian model
<MGR6P> : Chinese model
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EV
A001 CHASSIS --- 1 --- NSP
EV
A003 SCREW 4TTC+6C(3BC) 4 830440069GR
EV
A010 HOLDER (ML) 1 27191264A
EV
A013 HOLDER (MR) 1 27191265A
EV
A015 SCREW 3TTB+8B(3BC) 4 838430088GR
EV
A016 SCREW 3TTB+8B(CU)SR 8 801618
EV
A021 BRACKET (HT) 1 27130909
EV
A022 SCREW 5TTB+10B(3BC) 4 838450108GR
EV
A023 HEAT SINK 223DIE RG-418576 1 27160580
EV
A024 SCREW 3TTB+10B(3BC) 9 838430108GR
EV
A026 SCREW 3TTB+8B(CU)SR 4 801618
EV
A027 SCREW 3TTB+8B(CU)SR 7 801618
EV
A028 SCREW 3TTB+10B(3BC) 1 838430108GR
EV
A031 SCREW 3TTB+8B(CU)SR 3 801618
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
