27
Troubleshooting—Continued
does not work.
• There’s no RCA/phono analog audio connection. To use you must make an analog audio connection (RCA/phono)
between the DX-7355 and your Onkyo AV receiver, even if they are connected digitally.
Specifications
Signal readout: Optical non-contact
Frequency response: 4 Hz–20 kHz
SN ratio: 106 dB
Audio dynamic range: 100 dB
THD (total harmonic distortion): 0.0029%
Audio output
Digital optical: –22.5 dBm
Audio output/Impedance
Digital coaxial: 0.5 V (p-p), 75:
Audio output/Impedance
Analog: 2.0 V (rms), 600:
Power supply: AC 120/220–240 V, 50/60 Hz
AC 220–230 V, 50/60 Hz
Power consumption: Worldwide model: 15 W
Others: 14 W
Dimensions (W u H u D): 435 u 81 u 315 mm
Weight: 4.4 kg
Operation condition
Temperature, humidity: 5–35 °C, 5–85% (no condensation)
Supported discs: CD, CD-R, CD-RW, MP3
(Discs that have not been properly finalized may only be
partially playable or not playable at all.)
Specifications and features are subject to change without notice.
The DX-7355 contains a microcomputer for signal processing and control functions. In very rare
situations, severe interference, noise from an external source, or static electricity may cause it to
lockup. In the unlikely event that this should happen, unplug the power cord, wait at least 10
seconds, and then plug it again.
Onkyo is not responsible for damages (such as CD rental fees) due to unsuccessful recordings
caused by the unit’s malfunction. Before you record important data, make sure that the material
will be recorded correctly.
