Onkyo HT-R391B

4/44 PAGE
U0016
POWER SUPPLY(VP) PC BOARD ASS'Y
BAETC-1140-2D 1 1B2715140-2D <MDC, MDS>
U001
U0010 ～
～～
～ U0016
BAAF-1133-2E * 1 1B271533-2E <MMK, MMQ>
U0010
AUDIO PC BOARD ASS'Y
BAAF-1133-2E 1 1B2715133-2E <MMK, MMQ>
U0011
TERMINAL(DIGITAL) PC BOARD ASS'Y
BADG-1134-2E 1 1B2715134-2E <MMK, MMQ>
U0012
SENSOR PC BOARD ASS'Y
BAETC-1135-2E 1 1B2715135-2E <MMK, MMQ>
U0013
FIX PC BOARD
BAETC-1136-2E 1 1B2715136-2E <MMK, MMQ>
U0014
TERMINAL PC BOARD ASS'Y
BAETC-1137-2E 1 1B2715137-2E <MMK, MMQ>
U0015
FIX PC BOARD
BAETC-1138-2E 1 1B2715138-2E <MMK, MMQ>
U0016
POWER SUPPLY(VP) PC BOARD ASS'Y
BAETC-1140-2E 1 1B2715140-2E <MMK, MMQ>
U002
U0020 x 4 pcs.
BACLA-1130-2B * 1 1B271530-2B
U0020
AMPLIFIER PC BOARD ASS'Y
BACLA-1130-2B 1 1B2715130-2B
U00 ４
４４
４
U0040 ～
～～
～ U0044
BADIS-0654-3A * 1 1B271554-3A <MDC, MDS>
U0040
DISPLAY PC BOARD ASS'Y
BADIS-0654-3A 1 1B2715654-3A <MDC, MDS>
U0041
SWITCH PC BOARD ASS'Y
BADIS-0655-3A 1 1B2715655-3A <MDC, MDS>
U0042
VIDEO PC BOARD ASS'Y
BAVD-0656-3A 1 1B2715656-3A <MDC, MDS>
U0043
PHONE JACK PC BOARD ASS'Y
BAETC-0658-3A 1 1B2715658-3A <MDC, MDS>
U0044
POWER SUPPLY PC BOARD ASS'Y
BAPS-0659-3A 1 1B2715659-3A <MDC, MDS>
U00 ４
４４
４
U0040 ～
～～
～ U0044
BADIS-0654-3B * 1 1B271554-3B <MMK, MMQ>
U0040
DISPLAY PC BOARD ASS'Y
BADIS-0654-3B 1 1B2715654-3B <MMK, MMQ>
U0041
SWITCH PC BOARD ASS'Y
BADIS-0655-3B 1 1B2715655-3B <MMK, MMQ>
U0042
VIDEO PC BOARD ASS'Y
BAVD-0656-3B 1 1B2715656-3B <MMK, MMQ>
U0043
PHONE JACK PC BOARD ASS'Y
BAETC-0658-3B 1 1B2715658-3B <MMK, MMQ>
U0044
POWER SUPPLY PC BOARD ASS'Y
BAPS-0659-3B 1 1B2715659-3B <MMK, MMQ>
U005
U0050 x 2 pcs.
BAHDM-0678-3A * 1 0678-3A_HTR391MDC N <MDC, MDS>
U0050
HDMI(MAIN) PC BOARD ASS'Y
BAHDM-0678-3A 1 1B2715678-3A_R391MDC
N
<MDC, MDS>
U005
U0050 x 2 pcs.
BAHDM-0678-3A * 1 0678-3A_HTR391MMK N
<MMK, MMQ>
U0050
HDMI(MAIN) PC BOARD ASS'Y
BAHDM-0678-3A 1 1B2715678-3A_R391MMQ
N
<MMK, MMQ>
U010 TUNER UNIT FAEH08-W01 1 240169A
N
<B MDC, MDS>
U010 TUNER UNIT FAEH08-E01 1 240170A <B MMK, MMQ>
HT-R391
PACKING PROCEDURES PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[PACKING]
A601 PAD AS (AS) L & R 1 29092579A <B MDC, MDS, MMK, MMQ>
A601A PAD (L) 1 29092580A <B MDC, MDS, MMK, MMQ>
A601B PAD (R) 1 29092581A <B MDC, MDS, MMK, MMQ>
A605 POLY BAG w850xd650 1 29100245 <B>
A606 TAPE (SEROHAN)NITTO NO.29 1 29110149 <B>
A608 SHEET --- 1 29095906 <B MDC, MDS, MMK>
A608 SHEET T0.5x600x500 1 29096097 <B MMQ>
A611 TAPE (SEROHAN)NITTO NO.29 1 29110149 <B>
A672 POLY BAG w250xd350 1 29100250A <B MDC, MMK, MMQ>
A704A LABEL (DES)HTR391_C(B)MDC 1 29391874
N
<B MDC>
A704A LABEL (DES)HTR391_C(B)MDS 1 29391875
N
<B MDS>
A704A LABEL (DES)HTR391_C(B)MMK 1 29391876
N
<B MMK>
A704A LABEL (DES)HTR391_C(B)MMQ 1 29391877
N
<B MMQ>
HT-R391
PC BOARD PARTS LIST
U001 U0010 ～
～～
～ U0016
BAAF-1133-2D/2E *
U0010 AUDIO PC BOARD ASS'Y
BAAF-1133-2D/2E
