RL663 RELAY NRL-2P5A-DC24-129 1 25065563A
RL663 or RELAY NRL-2P8A-DC24-144 ( 1) 25065590
RL663 or RELAY NRL-2P8A-DC24-201 ( 1) 25065718 N
RL667 RELAY NRL-2P5A-DC24-129 1 25065563A
<B MDC, MDS, B MMK, MMQ>
RL667 or RELAY NRL-2P8A-DC24-144 ( 1) 25065590
<B MDC, MDS, B MMK, MMQ>
RL667 or RELAY NRL-2P8A-DC24-201 ( 1) 25065718 N
<B MDC, MDS, B MMK, MMQ>
RL669 RELAY NRL-2P5A-DC24-129 1 25065563A
RL669 or RELAY NRL-2P8A-DC24-144 ( 1) 25065590
RL669 or RELAY NRL-2P8A-DC24-201 ( 1) 25065718 N
[TUNER UNIT]
U131 PHT CP JSR1165-001recieving 1 24120143
U132 PHT CP JSR1165-001recieving 1 24120143
U002 U0020 x 4 pcs.
BACLA-1130-2B *
U0020 AMPLIFIER PC BOARD ASS'Y
BACLA-1130-2B
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D5000 ZENER D HZS6A3 1 224860560T
D5000 or ZENER D MTZJ5.6B ( 1) 224470562T
D5001 ZENER D HZS6A3 1 224860560T
D5001 or ZENER D MTZJ5.6B ( 1) 224470562T
D5002 ZENER D HZS6A3 1 224860560T
D5002 or ZENER D MTZJ5.6B ( 1) 224470562T
D5003 ZENER D HZS6A3 1 224860560T
D5003 or ZENER D MTZJ5.6B ( 1) 224470562T
D5004 ZENER D HZS6A3 1 224860560T
D5004 or ZENER D MTZJ5.6B ( 1) 224470562T
D5005 ZENER D HZS6A3 1 224860560T
D5005 or ZENER D MTZJ5.6B ( 1) 224470562T
Q5000 TR KTC3201-BL 1 2217946T
Q5001 TR KTC3201-BL 1 2217946T
Q5002 TR KTC3201-BL 1 2217946T
Q5003 TR KTC3201-BL 1 2217946T
Q5004 TR KTC3201-BL 1 2217946T
Q5005 TR KTC3201-BL 1 2217946T
Q5010 TR KTC3201-BL 1 2217946T
Q5011 TR KTC3201-BL 1 2217946T
Q5012 TR KTC3201-BL 1 2217946T
Q5013 TR KTC3201-BL 1 2217946T
Q5014 TR KTC3201-BL 1 2217946T
Q5015 TR KTC3201-BL 1 2217946T
Q5030 TR 2SA949-Y(TPE6_F) 1 2211354T
Q5030 or TR 2SA949-O(TPE6_F) ( 1) 2211353T
Q5030A RETAINER (CLA2) 1 27142140A
Q5031 TR 2SA949-Y(TPE6_F) 1 2211354T
Q5031 or TR 2SA949-O(TPE6_F) ( 1) 2211353T
Q5031A RETAINER (CLA2) 1 27142140A
Q5032 TR 2SA949-Y(TPE6_F) 1 2211354T
Q5032 or TR 2SA949-O(TPE6_F) ( 1) 2211353T
Q5032A RETAINER (CLA2) 1 27142140A
Q5033 TR 2SA949-Y(TPE6_F) 1 2211354T
Q5033 or TR 2SA949-O(TPE6_F) ( 1) 2211353T
Q5033A RETAINER (CLA2) 1 27142140A
Q5034 TR 2SA949-Y(TPE6_F) 1 2211354T
