Onkyo HT-R391B - Page 60

23/44 PAGE
R6073 NF CARBON R R25J-82 1 415478204T
R6074 NF CARBON R R25J-82 1 415478204T
R6075 NF CARBON R R25J-82 1 415478204T
[SW TRM]
P5507B TRM NTM-1P233(M1969) 1 25060302
P5509B TRM NTM-1P233(M1969) 1 25060302
P6000 SOCKET NSCT-9P2189 1 25052292
P6001 SOCKET NSCT-9P2189 1 25052292
P6002 SOCKET NSCT-9P2189 1 25052292
P6003 SOCKET NSCT-3P2183 1 25052286
P6004 SOCKET NSCT-9P2189 1 25052292
P6005 SOCKET NSCT-9P2189 1 25052292
P6013A SOCKET NSCT-7P2187 1 25052290
U004 U0040 ～
～～
～ U0044
BADIS-0654-3A/3B *
U0040 DISPLAY PC BOARD ASS'Y
BADIS-0654-3A/3B
U0041 SWITCH PC BOARD ASS'Y
BADIS-0655-3A/3B
U0042 VIDEO PC BOARD ASS'Y
BAVD-0656-3A/3B
U0043 PHONE JACK PC BOARD ASS'Y
BAETC-0658-3A/3B
U0044 POWER SUPPLY PC BOARD ASS'Y
BAPS-0659-3A/3B
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D7002 ZENER D DZ2J082M0L 1 224760820R2
D7002 or ZENER D UDZS8.2B ( 1) 224550820R2
D7033 ZENER D DZ2J039M0L 1 224760390R2
D7033 or ZENER D UDZS3.9B ( 1) 224550390R2
D7152 LED SLI-343Y8C-TE7 1 225490T
D7301 C-DIODE DA2J10100 1 223303R2
D7301 or C-DIODE 1SS352 ( 1) 223234R2
D7301 or C-DIODE 1SS355 ( 1) 223269R2
D7301 or C-DIODE MA2J111 ( 1) 223279R2
D7301 or C-DIODE KDS4148U ( 1) 223283R2
D7302 C-DIODE DA2J10100 1 223303R2
D7302 or C-DIODE 1SS352 ( 1) 223234R2
D7302 or C-DIODE 1SS355 ( 1) 223269R2
D7302 or C-DIODE MA2J111 ( 1) 223279R2
D7302 or C-DIODE KDS4148U ( 1) 223283R2
D7501 C-DIODE DA2J10100 1 223303R2
<B MDC, MDS, B MMK, MMQ>
D7501 or C-DIODE 1SS352 ( 1) 223234R2
<B MDC, MDS, B MMK, MMQ>
D7501 or C-DIODE 1SS355 ( 1) 223269R2
<B MDC, MDS, B MMK, MMQ>
D7501 or C-DIODE MA2J111 ( 1) 223279R2
<B MDC, MDS, B MMK, MMQ>
D7501 or C-DIODE KDS4148U ( 1) 223283R2
<B MDC, MDS, B MMK, MMQ>
D7502 C-DIODE DA2J10100 1 223303R2
<B MDC, MDS, B MMK, MMQ>
D7502 or C-DIODE 1SS352 ( 1) 223234R2
<B MDC, MDS, B MMK, MMQ>
D7502 or C-DIODE 1SS355 ( 1) 223269R2
<B MDC, MDS, B MMK, MMQ>
D7502 or C-DIODE MA2J111 ( 1) 223279R2
<B MDC, MDS, B MMK, MMQ>
D7502 or C-DIODE KDS4148U ( 1) 223283R2
<B MDC, MDS, B MMK, MMQ>
D7503 C-DIODE DA2J10100 1 223303R2
<B MDC, MDS, B MMK, MMQ>
D7503 or C-DIODE 1SS352 ( 1) 223234R2
<B MDC, MDS, B MMK, MMQ>
D7503 or C-DIODE 1SS355 ( 1) 223269R2
<B MDC, MDS, B MMK, MMQ>
D7503 or C-DIODE MA2J111 ( 1) 223279R2
<B MDC, MDS, B MMK, MMQ>
D7503 or C-DIODE KDS4148U ( 1) 223283R2
<B MDC, MDS, B MMK, MMQ>
D7504 C-DIODE DA2J10100 1 223303R2
<B MDC, MDS, B MMK, MMQ>
D7504 or C-DIODE 1SS352 ( 1) 223234R2
<B MDC, MDS, B MMK, MMQ>
