Service Mode
5 4 3
2
1
6
D
C
A
B
D
C
A
B
5 4 3
2
1
6
COMMON
If you use this function, you can select each parameter
by use press [Cursor Left] and [Cursor Right] button.
1. FAD Mode
The unit send HDCP authentication notice to Synchronism device(TV)
It has possibility of TV noise screen by timing of the HDCP communication.
If you have the claim from customer, you can test & fix the problem of no screen on TV
2. DOLBY VDB Thru
If the synchronism device(TV) is supported Dolby Vision,
The unit can send the signal of Dolby vision repeatable.
3. HDMI Thru
If the TV will power off when the standby-thru at the unit CEC working,
the AVR completely power off. The default setting should be 1 minute.
In fact, When the TV will be off at standby-thru mode, the unit should be power off
at one minute later.
This is debug mode, No necessary to use at the user claim.
3. Power Control
This mode just only appeared by set HDMI CEC on.
When it is set CEC-ON, The TV power off interlock unable or not.
5. TV Control
This mode just only appeared by set HDMI CEC on.
When it is set CEC-ON, The TV speaker interlock unable or not.
6. Max TMDSCR
The AVR (2015later) support 4K60p Max Pixel clock at 600MHz that means support 6GHz
It the TV support pixel clock up to 6GHz,
The AVR pass through 4K60p video signal repeatable.
This function that inform to the TV limit 3GHz. But the data is 6GHz.
If the customer’s TV can support 6GHz but the screen does not show any display,
You can test this function OK or not.
F A D M O D E : H D B
HDB: Default
On1: 400ms delay
On2: 1200ms delay
On3: 2700ms delay
Use this button
Use this button
D D V D B T h r u : O f f
On: Default
Off: Keep EDID of Dolby info.
H D M I T h r u : 1 m
OFF: Default=1 munites.
1s – 15m: 10sec – 15minutes
P o w e r C t r l : O n
On: Enable(Default)
Off: Disable
T V C t r l : O n
On: Enable(Default)
Off: Disable
T V C t r l : O n
600: 600MHz(Default)
300: 300MHz
