Service Mode
5432
1
6
D
C
A
B
D
C
A
B
5432
1
6
COMMON
7. LTE 340 SC
The TDMS clock is over 340MHz video input signal is enable scramble function
It is possible to send the signal stable at the over 340MHz TMDS clock.
When it is enable this function, it is enable scramble function at the under 340MHz
TMDS clock signal.
7. Thru Sel Change
Enable selector switching by remote control during standby through in ONKYO model.
Standby Sleep - Sets the validity / invalidity of selector switching
by remote control while keeping state.
MD1: Enable selector switching by remote control
only when Standby Thru setting is Last.
MD2: Standby Thru enables selector switching
by the remote control not only
when the setting is Last but also
when the selector is specified.
7. Pass thru MD
The monitor Out or Sub out with disable HDMI-CEC function,
It should be power down function setting at the standby-thru mode.
No necessary user this function at the user claim
8. Content Type
It is a setting whether or not to convey the four types of content
information of Graphics / Photo / Cinema / Game sent from Player to the TV.
On: Enable send the information from Player to TV.
Off: Disable this function.
No necessary user this function at the user claim
LTE 340 SC :Of f
Off: Disable(Default)
On: Enable
ThruSe lChg:MD1
MD1: Mode1(Default)
MD2: Mode2
Off: Disable
PassThruMD :Of f
Off:
On:
PassThruMD :Of f
On: Enable (Default)
Off: Disable
Describe Service Mode (1-3 Video) 2/2
To Next Page
