Onkyo HT-R558 Service Manual

6/70 PAGE
U0015
FIX PC BOARD
BAETC-1138-2C 1 1B2715138-2C <MMR, MMQ>
U0016
POWER SUPPLY(VP) PC BOARD ASS'Y
BAETC-1140-2C 1 1B2715140-2C <MMR, MMQ>
U002
U0020 x 4 pcs.
BACLA-1130-2A * 1 1B271530-2A
U0020
AMPLIFIER PC BOARD ASS'Y
BACLA-1130-2A 1 1B2715130-2A
U004
U0040〜U0044
BADIS-0654-3D * 1 1B271554-3D N
U0040
DISPLAY PC BOARD ASS'Y
BADIS-0654-3D 1 1B2715654-3D
N
U0041
SWITCH PC BOARD ASS'Y
BADIS-0655-3D 1 1B2715655-3D
U0042
VIDEO PC BOARD ASS'Y
BAVD-0656-3D 1 1B2715656-3D
U0043
PHONE JACK PC BOARD ASS'Y
BAETC-0658-3D 1 1B2715658-3D
U0044
POWER SUPPLY PC BOARD ASS'Y
BAPS-0659-3D 1 1B2715659-3D
U005
U0050 x 2 pcs.
BAHDM-0678-3A * 1 1B271578-3A
U0050
HDMI(MAIN) PC BOARD ASS'Y
BAHDM-0678-3A 1 1B2715678-3A
U010 TUNER UNIT FAEH08-E01 1 240170A <B MMQ, MPA, MPP, MMR / S MPP>
HT-R558
PACKING PROCEDURES PARTS LIST
<Notes>
(B) : Black model
(S) : Silver model
<MPP> : 230V,CE(European) country model
<MPA> : 230V,Australian model
<MMR> : 220/230-240V,Chinese model
<4505MPP> : 230V,CE(European) country model for HT-S4505
<4505MPA> : 230V,Australian modell for HT-S4505
<4505MMQ> : 220/230-240V,Hong kong model for HT-S4505
REF. N
O
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[PACKING]
A601 PAD AS (AS)309 L & R 1 29092570B <B MMR, MPA, MPP>
A601A PAD (L) 1 29092571B <B MMR, MPA, MPP>
A601B PAD (R) 1 29092572B <B MMR, MPA, MPP>
