Onkyo HT-R558 Service Manual

8/70 PAGE
A861 or BATTERY R6/AA(UM-3) ( 2) 3010054 <B MPA, MPP>
A891 WRNTY CARD (ONKYO-CH) 1 29365098C <B MMR>
A911 INS MANUAL En(HTS4505) 1 29401054 <B MPA, MPP>
A913 INS MANUAL Cs(HTR558) 1 29401087
N
<B MMR>
A918 INS MANUAL U3_FrEsIt(HTR558) 1 29401085
N
<B MPP>
A919 INS MANUAL U3_DeNlSv(HTR558) 1 29401086
N
<B MPP>
A951 INS MANUAL QSG_En(HTR558) 1 29401088
N
<B MPA, MPP>
A953 INS MANUAL QSG_Cs(HTR558) 1 29401089
N
<B MMR>
HT-R558
PC BOARD PARTS LIST
U001
U0010〜U0016
BAAF-1133-2B/2C *
U0010
AUDIO PC BOARD ASS'Y
BAAF-1133-2B/2C
U0011
TERMINAL(DIGITAL) PC BOARD ASS'Y
BADG-1134-2B/2C
U0012
SENSOR PC BOARD ASS'Y
BAETC-1135-2B/2C
U0013
FIX PC BOARD
BAETC-1136-2B/2C
U0014
TERMINAL PC BOARD ASS'Y
BAETC-1137-2B/2C
U0015
FIX PC BOARD
BAETC-1138-2B/2C
U0016
POWER SUPPLY(VP) PC BOARD ASS'Y
BAETC-1140-2B/2C
CIRCUIT
N
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D131 C-DIODE DA2J10100 1 223303R2
D131 or C-DIODE KDS4148U ( 1) 223283R2
D132 C-DIODE DA2J10100 1 223303R2
D132 or C-DIODE KDS4148U ( 1) 223283R2
D4171 ZENER D HZS7B1 1 224860680T
D4171 or ZENER D MTZJ6.8B ( 1) 224470682T
D4172 ZENER D HZS7B1 1 224860680T
D4172 or ZENER D MTZJ6.8B ( 1) 224470682T
D4300 DIODE RL1N4003 1 22380260T
D4300 or DIODE GP104003E ( 1) 22380035T

Onkyo HT-R558 Specifications

General

Brand	Onkyo
Model	HT-R558
Category	Receiver
Language	English
