1/69 PAGE
HT-R560
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
<Notes>
(B) : Black model
(S) : Silver model
<MDD> : USA model
<MDC> : Canadian model
<MPP> : European model
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EXPLODED
A001 CHASSIS (FRONT) 1 27100513A
EXPLODED
A002 SCREW 3TTB+8B(3CM)SR 5 801637
EXPLODED
A003 B PLATE --- 1 28133425
(B)
EXPLODED
A003 B PLATE --- 1 28133426
(S)
EXPLODED
A004 RETAINER (F) 1 27142099
EXPLODED
A005 SCREW 3TTB+8B(3CM)SR 2 801637
EXPLODED
A011 SCREW 2.6TTB+8B(3BC) 18 838426088GR
EXPLODED
A012 SCREW 2.6TTB+8B(3BC) 3 838426088GR
EXPLODED
A013 WIRE TIE BSK-1 8 260208
EXPLODED
A016 SCREW 3TTB+8B(3CM)SR 1 801637
EXPLODED
A018 HOLDER KGLS-22S 3 27190369
EXPLODED
A020 HOLDER KGLS-16RT 2 27190511
EXPLODED
A021 HOLDER KGPS-16RF 5 27190991
EXPLODED
A022 HOLDER KGLS-10RT 1 27190428A
EXPLODED
A030 SCREW 4TTC+8C(3BC) 4 830440089GR
