Onkyo HT-R560 Service Manual

8/69 PAGE
PCB1
Q6000 TR 2SC1740S-S 1 2213285T
PCB1
Q6001 TR 2SC1740S-S 1 2213285T
PCB1
Q6002 TR 2SC1740S-S 1 2213285T
PCB1
Q6003 TR 2SC1740S-S 1 2213285T
PCB1
Q6004 TR 2SC1740S-S 1 2213285T
PCB1
Q6005 TR 2SC1740S-S 1 2213285T
PCB1
Q6006 TR 2SC1740S-S 1 2213285T
PCB1
Q6010 TR 2SC1740S-S 1 2213285T
PCB1
Q6011 TR 2SC1740S-S 1 2213285T
PCB1
Q6012 TR 2SC1740S-S 1 2213285T
PCB1
Q6013 TR 2SC1740S-S 1 2213285T
PCB1
Q6014 TR 2SC1740S-S 1 2213285T
PCB1
Q6015 TR 2SC1740S-S 1 2213285T
PCB1
Q6016 TR 2SC1740S-S 1 2213285T
PCB1
Q6030 TR 2SC5171(ONK_Q) 1 2203010
PCB1
Q6030 or TR 2SC5993-Q_P (1) 2217161
PCB1
Q6031 TR 2SC5171(ONK_Q) 1 2203010
PCB1
Q6031 or TR 2SC5993-Q_P (1) 2217161
PCB1
Q6032 TR 2SC5171(ONK_Q) 1 2203010
PCB1
Q6032 or TR 2SC5993-Q_P (1) 2217161
PCB1
Q6033 TR 2SC5171(ONK_Q) 1 2203010
PCB1
Q6033 or TR 2SC5993-Q_P (1) 2217161
PCB1
Q6034 TR 2SC5171(ONK_Q) 1 2203010
PCB1
Q6034 or TR 2SC5993-Q_P (1) 2217161
PCB1
Q6035 TR 2SC5171(ONK_Q) 1 2203010
PCB1
Q6035 or TR 2SC5993-Q_P (1) 2217161
PCB1
Q6036 TR 2SC5171(ONK_Q) 1 2203010
PCB1
Q6036 or TR 2SC5993-Q_P (1) 2217161
PCB1
Q6040 TR 2SA1930(ONK_Q) 1 2203000
PCB1
Q6040 or TR 2SA2140-Q_P (1) 2217151
PCB1
Q6041 TR 2SA1930(ONK_Q) 1 2203000
PCB1
Q6041 or TR 2SA2140-Q_P (1) 2217151
PCB1
Q6042 TR 2SA1930(ONK_Q) 1 2203000
