Onkyo HT-R560 Service Manual

13/69 PAGE
PCB1
C5000 TF C ECQ-B50V-221K 1 374722215T
PCB1
C5001 TF C ECQ-B50V-221K 1 374722215T
PCB1
C5002 TF C ECQ-B50V-221K 1 374722215T
PCB1
C5003 TF C ECQ-B50V-221K 1 374722215T
PCB1
C5004 TF C ECQ-B50V-221K 1 374722215T
PCB1
C5005 TF C ECQ-B50V-221K 1 374722215T
PCB1
C5006 TF C ECQ-B50V-221K 1 374722215T
PCB1
C5010 UTSP C CE04W50V 47M(UTSP) 1 397584707T
PCB1
C5011 UTSP C CE04W50V 47M(UTSP) 1 397584707T
PCB1
C5012 UTSP C CE04W50V 47M(UTSP) 1 397584707T
PCB1
C5013 UTSP C CE04W50V 47M(UTSP) 1 397584707T
PCB1
C5014 UTSP C CE04W50V 47M(UTSP) 1 397584707T
PCB1
C5015 UTSP C CE04W50V 47M(UTSP) 1 397584707T
PCB1
C5016 UTSP C CE04W50V 47M(UTSP) 1 397584707T
PCB1
C5020 UTSP C CE04W50V-10M(UTSP) 1 397581007T
PCB1
C5021 UTSP C CE04W50V-10M(UTSP) 1 397581007T
PCB1
C5022 UTSP C CE04W50V-10M(UTSP) 1 397581007T
PCB1
C5023 UTSP C CE04W50V-10M(UTSP) 1 397581007T
PCB1
C5024 UTSP C CE04W50V-10M(UTSP) 1 397581007T
PCB1
C5025 UTSP C CE04W50V-10M(UTSP) 1 397581007T
PCB1
C5026 UTSP C CE04W50V-10M(UTSP) 1 397581007T
PCB1
C5040 UTSP C CE04W25V-220M(UTSP) 1 397552217T
PCB1
C5041 UTSP C CE04W25V-220M(UTSP) 1 397552217T
PCB1
C5042 UTSP C CE04W25V-220M(UTSP) 1 397552217T
PCB1
C5043 UTSP C CE04W25V-220M(UTSP) 1 397552217T
PCB1
C5044 UTSP C CE04W25V-220M(UTSP) 1 397552217T
PCB1
C5045 UTSP C CE04W25V-220M(UTSP) 1 397552217T
PCB1
C5046 UTSP C CE04W25V-220M(UTSP) 1 397552217T
PCB1
C5050 UTSP C CE04W50V 47M(UTSP) 1 397584707T
PCB1
C5051 UTSP C CE04W50V 47M(UTSP) 1 397584707T
PCB1
C5052 UTSP C CE04W50V 47M(UTSP) 1 397584707T
PCB1
C5053 UTSP C CE04W50V 47M(UTSP) 1 397584707T
PCB1
C5054 UTSP C CE04W50V 47M(UTSP) 1 397584707T
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Onkyo HT-R560 Specifications

General

Type	AV Receiver
Number of Channels	7.1
HDMI Outputs	1
Component Video Outputs	1
Digital Audio Inputs (Optical)	2
Digital Audio Inputs (Coaxial)	1
Headphone Jack	Yes
Tuner Presets	40
Amplifier Type	Discrete
Frequency Response	10 Hz - 100 kHz
Input Sensitivity	200 mV
Signal-to-Noise Ratio	100 dB
Speaker Impedance	6 Ohms
USB Port	No
Bluetooth	No
Wi-Fi	No
