Onkyo HT-R570 - Page 71

PCB-2
R808 C-CARBON R RN72K1J-000JE 1 435030004R1 <1K>
PCB-2
R810 C-CARBON R RN72K1J-000JE 1 435030004R1 <1K>
PCB-2
R812 C-CARBON R RN72K1J-000JE 1 435030004R1 <1K>
PCB-2
R814 C-CARBON R RN72K1J-000JE 1 435030004R1
PCB-2
R815 C-CARBON R RN72K1J-000JE 1 435030004R1
[SW TRM]
PCB-2
JL5501B WIRE TRAP NPLG-3P586 1 25055624 <1K>
PCB-2
JL6610B WIRE TRAP NPLG-7P590 1 25055628 <1K>
PCB-2
JL901B WIRE TRAP NPLG-5P588 1 25055626
PCB-2
P002 PWB BCDG-0022 1 25140022C N
PCB-2
P101A SOCKET NSCT-11P2104 1 25052207
PCB-2
P131 PIN JACK NPJ-2PDOO626 1 25045847 <1K>
PCB-2
P131 or PIN JACK NPJ-2PDO445 ( 1) 25045640 <1K>
PCB-2
P2001A SOCKET IMSA-9142S-26A 1 25053235
PCB-2
P2080B PLUG IMSA-9142B-20A 1 25056600 <1K>
PCB-2
P2081 SOCKET NNA1-01-006 1 25053357 N <1K>
PCB-2
P5501A SOCKET NSCT-7P2187 1 25052290
PCB-2
P5502A SOCKET NSCT-15P2195 1 25052298
PCB-2
P5503A SOCKET NSCT-9P2189 1 25052292
PCB-2
P5504A SOCKET NSCT-7P2187 1 25052290 <1K>
PCB-2
P701A SOCKET NSCT-33P2126 1 25052229 <1K>
PCB-2
P751A SOCKET IMSA-9618S-09A 1 25053334R2
PCB-2
P8001A PLUG IMSA-9111B-24 1 25056625
U003 DISPLAY PC BOARD (BADIS-0036-1M)
U00031 DISPLAY PC BOARD (BADIS-003741M)
U00032 VIDEO PC BOARD (BAVD-0038-1M)
U00033 POWER SUPPLY PC BOARD (BAPS-0039-1M)
U00034 HPJACK PC BOARD (BAETC-0040-1M)
CIRCUIT. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[TUNER UNIT]
PCB-3
U7042 REMO SENS NJL34H380A 1 241365
[SEMI CONDUCTOR]
PCB-3
D2084 ZENER D UDZS6.8B 1 224550680R2 <1M>
PCB-3
D7002 ZENER D UDZS8.2B 1 224550820R2
PCB-3
D7033 ZENER D UDZS3.9B 1 224550390R2
