Onkyo HT-R590

6/58 PAGE
PV
A859 FM ANT AS Type W 1 292191
PV
A861 BATTERY R6/AA(UM-3) 2 3010194 <MMK, MMQ>
PV
A861 BATTERY R6/AA(UM-3) 2 3010506 <MDC, MDD, MDS>
PV
A861 or BATTERY R6/AA(UM-3) ( 2) 3010054 <MDC, MDD, MDS, MMK, MMQ>
PV
A861 or BATTERY R6/AA(UM-3) ( 2) 3010194 <MDC, MDD, MDS>
PV
A884 WRNTY CARD MGQ 1 29365099A <MMQ>
PV
A885 WRNTY CARD (ONKYO) 1 29365135 <MDC, MDD, MDS>
HT-R590
U001
PC BOARD PARTS LIS
T
U001
U001
U001 U0010 + U0011 + U0012 + U0013 + U0014 + U0015 + U0016 + U0017
U001
U0010
Power Amp / Audio Input Terminals PC board BAAF-0621-1A/ 1B
U001
U0011
Center Speaker Terminal PC Board BATRM-0622-1A/ 1B
U001
U0012
Thermal Senser PC board BAETC-0623-1A/ 1B
U001
U0013
Spacer PC board BAETC-0624-1A/ 1B
U001
U0014
Terminal PC board BAETC-0625-1A/ 1B
U001
U0015
FFC Fixture PC board BAETC-0626-1A/ 1B
U001
U0016
Power supply PC board BAETC-0627-1A/ 1B
U001
U0017
Part Fixture PC board BAETC-0764-1A/ 1B
U001
U001
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
U001
[SEMI CONDUCTOR]
U001
D4171 ZENER D MTZJ6.8B 1 224470682T
U001
D4172 ZENER D MTZJ6.8B 1 224470682T
U001
D4208 C-DIODE DA2J10100 1 223303R2
U001
D4208 or C-DIODE 1SS352 ( 1) 223234R2
U001
D4208 or C-DIODE 1SS355 ( 1) 223269R2
U001
D4208 or C-DIODE MA2J111 ( 1) 223279R2
U001
D4208 or C-DIODE KDS4148U ( 1) 223283R2
U001
D4218 C-DIODE DA2J10100 1 223303R2
U001
D4218 or C-DIODE 1SS352 ( 1) 223234R2
U001
D4218 or C-DIODE 1SS355 ( 1) 223269R2
U001
D4218 or C-DIODE MA2J111 ( 1) 223279R2
U001
D4218 or C-DIODE KDS4148U ( 1) 223283R2
U001
D4300 DIODE RL1N4003 1 22380260T
U001
D4300 or DIODE GP104003E ( 1) 22380035T
U001
D4301 DIODE RL1N4003 1 22380260T
U001
D4301 or DIODE GP104003E ( 1) 22380035T
