Onkyo HT-R520 Service Manual (English)

Other manuals for Onkyo HT-R520

Questions and Answers:

A
Andre McguireJul 26, 2025
Why is there no sound coming from my Onkyo HT-R520 Receiver speakers?
- D
  devin45Jul 26, 2025
  Several factors can cause a lack of sound from your Onkyo Receiver. First, ensure that the receiver is not muted. If the MUTING indicator is on, unmute the receiver. Check the audio connections to confirm that all plugs are fully inserted. Verify the speaker cables are correctly connected, paying attention to polarity. Select the correct input source on your TV to match the receiver's connection. Remove any connected headphones. Ensure the input signal format is set to Auto, not PCM or DTS. Adjust the volume to an audible level. Configure the speakers correctly, specifying which ones are connected, their distances, and individual levels. Confirm that the source component is outputting digital audio and that a compatible digital audio format is selected on the source component.
D
davisthomasJul 31, 2025
What to do if Onkyo HT-R520 Receiver remote is not working?
- F
  fweissJul 31, 2025
  If the buttons on your Onkyo HT-R520 receiver itself work, but the remote controller does not, it could be due to several reasons. First, ensure that you have selected the correct remote controller mode. Next, check the batteries in the remote to make sure they are installed correctly. Finally, be sure to point the remote controller directly at the remote sensor on the HT-R520.
C
costajohnAug 5, 2025
How to fix a quiet center speaker on my Onkyo Receiver?
- D
  Denise HernandezAug 5, 2025
  The center speaker might not be working or may sound very quiet on your Onkyo Receiver if the Stereo, Direct, or Orchestra listening mode is selected; try changing the listening mode. Also, the level of the center speaker may be set at minimum; adjust the center speaker level accordingly. Finally, check that the Center setting is not set to None in the Speaker Configuration and change it if needed.
S
Susan ArmstrongAug 10, 2025
Why are the surround speakers not working on my Onkyo HT-R520 Receiver?
- B
  Bradley LarsenAug 10, 2025
  If the surround speakers on your Onkyo receiver aren't working, it could be due to a few reasons. First, the selected listening mode may not utilize surround speakers, so try changing to a mode that does. Also, remember that surround speaker output depends on the source material, so ensure you're using a source that supports surround sound. Check that the level of the surround speakers is not set to minimum and adjust it if necessary. Finally, verify that the Surround setting is not set to None in the Speaker Configuration; change it if needed.
E
Edward ColeAug 15, 2025
How to troubleshoot a quiet subwoofer on my Onkyo HT-R520?
- W
  William ReillyAug 15, 2025
  The subwoofer on your Onkyo receiver might not be working or may be very quiet due to several reasons. First, check the Subwoofer setting in the Speaker Configuration to ensure it is not set to No. Increase the subwoofer volume if it is set to minimum. Also, make sure speaker set A is turned on, as the subwoofer output does not function when only speaker set B is active.
T
Teresa MorrisonAug 20, 2025
Why can’t I record surround-sound effects on my Onkyo Receiver?
- T
  Thomas BradshawAug 20, 2025
  This is normal. The surround-sound effects produced by the listening modes cannot be recorded.

Onkyo HT-R520 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Output	1
Input sensitivity	200 mV
Component Video Inputs	2
Composite Video Inputs	3
Component Video Outputs	1
Composite Video Outputs	1
Total Harmonic Distortion	0.08%
Frequency Response	10 Hz - 100 kHz
Audio Formats Supported	Dolby TrueHD, DTS-HD Master Audio
Tuning range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
Speaker impedance	6 ohms
Signal to noise ratio	100 dB
Output	Speaker
Video Connections	Composite
Audio Inputs	Digital Optical, Digital Coaxial
Audio Outputs	Analog, Digital Optical
HDMI Version	1.4
Input Sensitivity and Impedance	200 mV / 47 kΩ
