Onkyo HT-R590

24/58 PAGE
U001
RL662 or RELAY NRL-2P5A-DC24-193 ( 1) 25065703
U001
RL663 RELAY NRL-2P5A-DC24-129 1 25065563A
U001
RL663 or RELAY NRL-2P5A-DC24-193 ( 1) 25065703
U001
RL665 RELAY NRL-2P5A-DC24-129 1 25065563A <MDC, MDD, MDS, MMK, MMQ>
U001
RL665 or RELAY NRL-2P8A-DC24-144 ( 1) 25065590 <MDC, MDD, MDS, MMK, MMQ>
U001
RL665 or RELAY NRL-2P5A-DC24-193 ( 1) 25065703 <MDC, MDD, MDS, MMK, MMQ>
U001
RL691 RELAY NRL-1P10A-DC12-196 1 25065707
U001
RL691 or RELAY NRL-1P10A-DC12-197 ( 1) 25065708
U001
RL691 or RELAY NRL-1P10A-DC12-198 ( 1) 25065709
U001
RL692 RELAY NRL-1P10A-DC12-196 1 25065707
U001
RL692 or RELAY NRL-1P10A-DC12-197 ( 1) 25065708
U001
RL692 or RELAY NRL-1P10A-DC12-198 ( 1) 25065709
U001
RL693 RELAY NRL-1P10A-DC12-140 1 25065584
U001
RL693 or RELAY NRL-1P10A-DC12-143 ( 1) 25065588
U001
RL694 RELAY NRL-1P10A-DC12-140 1 25065584
U001
RL694 or RELAY NRL-1P10A-DC12-143 ( 1) 25065588
U002
U002 U0020 + U0021 + U0022 + U0023 + U0024
U002
U0020
Display PC board BADIS-0654-1E/ 1F
U002
U0021
Standby switch PC board BADIS-0655-1E/ 1F
U002
U0022
Video PC board BAVD-0656-1E/ 1F
U002
U0023
HP Jack PC board BAETC-0658-1E/ 1F
U002
U0024
Power supply PC board BAPS-0659-1E/ 1F
U002
U002
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
U002
[SEMI CONDUCTOR]
U002
D7002 ZENER D DZ2J082M0L 1 224760820R2
U002
D7002 or ZENER D UDZS8.2B ( 1) 224550820R2
U002
D7033 ZENER D DZ2J039M0L 1 224760390R2
U002
D7033 or ZENER D UDZS3.9B ( 1) 224550390R2
U002
D7152 LED SLI-343Y8C-TE7 1 225490T
U002
D7301 C-DIODE DA2J10100 1 223303R2 N
U002
D7301 or C-DIODE 1SS352 ( 1) 223234R2
U002
D7301 or C-DIODE 1SS355 ( 1) 223269R2
U002
D7301 or C-DIODE MA2J111 ( 1) 223279R2
U002
D7301 or C-DIODE KDS4148U ( 1) 223283R2
U002
D7302 C-DIODE DA2J10100 1 223303R2 N
U002
D7302 or C-DIODE 1SS352 ( 1) 223234R2
U002
D7302 or C-DIODE 1SS355 ( 1) 223269R2
