_] vNN'g_
You can assign a default listening mode to each input
source that will be selected automatically when you select
each input source. For example, you can set the default
listening mode to be used with Dolby Digital input
signals. You can select other listening modes during
playback, but the mode specified here will be resumed
once the AV receiver has been set to standby.
1 Use A/¥ to select the input source that you want to
set, and then press ENTER.
The following menu appears.
I
I
DTS/DTS-ES/DTS-HD
With this setting, you can specify the listening mode
used when DTS or DTS-HD High Resolution format
digital audio signals are played (DVD, LD, CD, etc.).
Specifies the default listening mode for DTS-HD
Master Audio sources, such as Blu-ray or HD DVD
(input via HDMI).
Other Multich Source
Specifies the default listening mode for multichannel
PCM sources from HDMI IN such as DVD-Audio, and
DSD multichannel sources such as Super Audio CD.
5. Listening ModePreset
2. MCR/DVR
3. CBUSAT
4. GAME
5. AUX
2 Use A/¥ to select the signal format that you want to
set, and then use _/_ to select a listening mode.
Only listening modes that can be used with each input
signal format can be selected (_ pages 34 to 38).
The "Last Valid" option means that the listening
mode selected last will be used.
If you connect an inputcomponent (such as UP-A 1series
Dock that seated iPod) to the UNIVERSAL PORTjack,
the only listening modes you can assign to the "PORT"
selectorare specific to analog sound.
For theTUNER input selector,only "Analog" will be
available.
For the NETor USB input selector,only "Digital" will be
available.
I Analog / PCM / Digital
With this setting, you can specify the listening mode
used when an analog (CD, TV, LD, VHS, MD,
turntable, radio, cassette, cable, satellite, etc.) or PCM
digital (CD, DVD, etc.) audio signal is played.
I Mono/Multiplex Source
With this setting, you can specify the listening mode
used when a mono digital audio signal is played (DVD,
etc.).
12ch Source
With this setting, you can specify the listening mode
used when 2-channel (2/0) stereo digital sources, such
as Dolby Digital or DTS, are played.
I Dolby D/Dolby D Plus/TrueHD
With this setting, you can specify the listening mode
used when Dolby Digital or Dolby Digital Plus format
digital audio signals are played (DVD, etc.). Specifies
the default listening mode for Dolby TrueHD sources,
such as Blu-ray or HD DVD (input via HDMI).
Volume Setup
I Volume Display
Absolute:
Displayed range is Min, 0.5 to 99.5, Max.
Relative (THX):
Displayed range is -oodB, -81.5dB to +18.0dB.
With this setting, you can choose how the volume level is
displayed.
The absolute value 82 is equivalent to the relative value
0 dB.
ff the absolute value is set to 82, "82ReF' will appear on the
display and the THX indicator will flash.
I Muting Level
-oodB (fully muted), -50dB to -10dB in 10 dB steps.
This setting determines how much the output is muted
when the muting function is used (_ page 40).
I Maximum Volume
iff, 50 to 99 (Ahsolute display)
iff, -32dB to +17dB (Relative display)
With this setting, you can limit the maximum volume.
To disable this setting, select "ifF'.
I Power On Volume
Last, Min, 1 to 99 or Max (Ahsolute display)
Last, -oodB, -81dB to +18dB (Relative display)
With this preference, you can specify the volume setting
to be used each time the AV receiver is turned on.
To use the same volume level that was used when the AV
receiver was turned off, select "Last".
The "Power in Volume" cannot be set higher than the
"Maximum Volume" setting.
I Headphone Level
-12dB to 0dB to +12dB
With this preference, you can specify the headphone
volume relative to the main volume. This is useful if
there's a volume difference between your speakers and
your headphones.
En
53
