Appendix
En-78
The AV receiver can upconvert component video and
composite video sources for display on a TV connected to
the HDMI output(s). However, if the picture quality of the
source is poor, upconversion may make the picture worse
or disappear altogether.
In this case, try the following:
Tip
• To by-pass the upconversion, set the “Picture Mode” setting to
“Direct” (➔ page 56).
Important Note Regarding Video Playback
1
If the video source is connected to a component
video input, connect your TV to COMPONENT
VIDEO OUT.
If the video source is connected to a composite video
input, connect your TV to MONITOR OUT V.
2
On the main menu, select “Input/Output Assign”,
and then select “Component Video Input”
(➔ page 49).
If the video source is connected to COMPONENT
VIDEO IN, select the relevant input selector, and
assign it to “IN1”.
If the video source is connected to a composite video
input, select the relevant input selector, and assign it to
“-----”.
To Next Page
