1. HDMI OUT jacks: Transmit video signals and audio signals with an HDMI
cable connected to a TV.
2. HDMI IN jacks: Transmit video signals and audio signals with an HDMI cable
connected to an AV component.
3. POWER OUT port: You can also supply power (5 V/1 A) to the Streaming
media player connected to the HDMI IN terminal of this unit with a USB cable.
( p42) The playback function of music les and power supply to smart
phones/tablets, or other devices are not supported.
4. Power cord
5. DIGITAL IN OPTICAL/COAXIAL jacks: Input TV or AV component digital audio
signals with a digital optical cable or digital coaxial cable.
6. TUNER AM/FM terminal: Connect the supplied antennas.
7. AUDIO IN jacks: Input TV or AV component audio signals with an analog audio
cable.
8. ZONE B PRE/LINE OUT jacks: Output audio signals with an analog audio
cable connected to a pre-main amplier or a power amplier in a separate
room (ZONE B).
9. SUBWOOFER PRE OUT jacks: Use the subwoofer cable to connect the
supplied powered subwoofer. A maximum of two powered subwoofers can be
connected. (Purchase a second powered subwoofer separately.) The same
signal is output from each SUBWOOFER PRE OUT jack.
10.
SPEAKERS terminals: Connect the supplied speakers with speaker cables.
(FRONT L/R terminals support banana plugs.)
