Adjusting the tone
Adjusting TREBLE/BASS
You can adjust the sound quality of the front speakers.
1. Press TREBLE or BASS to select the setting to adjust.
TREBLE: Enhances or moderates the high-tone range of the front speakers.
BASS: Enhances or moderates the low-tone range of the front speakers.
2. Press + or - for adjustment.
Adjusting VOCAL
Emphasizes movie lines and music vocals to listen to them more easily. It is
effective to movie lines in particular. Also, it exerts the effect even if the center
speaker is not used. Select a desired level from "1" (low) to "5" (high).
1. Press VOCAL.
2. Press + or
- for adjustment.
• Depending on the input source or listening mode setting, selection is not
possible, or the desired effect may not be achieved.
TREBLE
VOCAL
BASS
+
-

Onkyo HT-S5910 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
4Ω speaker support	No
Audio output channels	5.1.2 channels
Total Harmonic Distortion (THD)	0.08 %
Dynamic power per channel (3 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	115 W
Display	LCD
Product color	Black
Audio decoders	Dolby Atmos
Damping factor	60
Amplifier output power	925 W
HDMI in	4
Composite video in	3
Digital audio coaxial in	1
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	0
Audio (L/R) out	7
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Supported radio bands	AM, FM
AC input voltage	120 V
AC input frequency	60 Hz

Weight and Dimensions

Depth	328 mm
Width	453 mm
Height	160 mm
Weight	7800 g
