General Specications
Amplier Section
Rated Output Power (FTC)
With 8 ohm loads, both channels driven, from 20-20,000 Hz; rated 80 watts
per channel minimum RMS power, with no more than 0.08% total harmonic
distortion from 250 milliwatts to rated output.
Maximum Effective Output Power
160 W at 6 ohms, 1 kHz, 1 ch driven of 10% THD
Dynamic Power (*)
* IEC60268-Short-term maximum output power
160 W (3 Ω, Front)
125 W (4 Ω, Front)
85 W (8 Ω, Front)
THD+N (Total Harmonic Distortion+Noise)
0.08% (20 Hz - 20,000 Hz, half power)
Input Sensitivity and Impedance
200 mV/47 kΩ (LINE (RCA))
Rated RCA Output Level and Impedance
1 V/470 Ω (SUBWOOFER PRE OUT)
1 V/2.3 kΩ (ZONE B PRE/LINE OUT)
Frequency Response
10 Hz - 100 kHz/+1 dB, –3 dB (Direct)
Tone Control Characteristics
±10 dB, 20 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio
109 dB (IHF-A, LINE IN, SP OUT)
Speaker Impedance
4 Ω - 16 Ω
Headphone Rated Output
80 mW + 80 mW (32 Ω, 1 kHz, 10% THD)
Supported impedance of Headphones
8 Ω - 600 Ω
Headphones Frequency Response
10 Hz - 100 kHz
Tuner Section
FM Tuning Frequency Range
87.5 MHz - 107.9 MHz
50 dB quieting sensitivity (FM MONO)
1.0 μV, 11.2 dBf (IHF, 1 kHz, 100% MOD)
AM Tuning Frequency Range
530 kHz - 1710 kHz
Preset Channel
40
BLUETOOTH Section
Communication system
BLUETOOTH Specication version 4.2
Frequency band
2.4 GHz band
Modulation method
FHSS (Freq Hopping Spread Spectrum)
Compatible BLUETOOTH proles
A2DP 1.3
AVRCP 1.5
HFP(Hands-Free Prole) 1.6
HSP(Headset Prole) 1.2
SPP(Serial Port Prole) 1.2
Supported Codecs
SBC
AAC
Transmission range (A2DP)
20 Hz - 20 kHz (Sampling frequency 44.1 kHz)
Maximum communication range
Line of sight approx. 15 m (*)
* The actual range will vary depending on factors such as obstacles between
