devices, magnetic elds around a microwave oven, static electricity,
cordless phone, reception sensitivity, antenna's performance, operating
system, software application, etc.
General
Power Supply
120 V AC, 60 Hz
Power Consumption
490 W
0.1 W (Full Standby mode)
0.1 W (HDMI CEC)
43.2 W (No-sound)
27.4 W (HDMI Standby Through)
Dimensions (W × H × D)
435 mm × 160 mm × 328 mm
17-1/8" × 6-5/16" × 12-15/16"
Weight
8.2 kg (18.1 lbs.)
HDMI
Input
IN1 (BD/DVD), IN2 (GAME), IN3 (CBL/SAT), IN4 (STRM BOX)
Output
OUT
Supported
Audio Return Channel, 3D, 4K 60 Hz, 6G, HDR10, BT.2020, HLG, Dolby
Vision, Auto Lip Sync, CEC
Audio Format
Dolby Atmos, Dolby TrueHD, Dolby Digital, Dolby Digital Plus, DTS, DTS:X,
DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS 96/24, DTS-
ES, DTS Express, DSD (PCM Conversion Input), 2-channel linear PCM,
Multi-channel linear PCM
HDCP version
2.2
Maximum Video Resolution
4K 60 Hz (YCbCr 4:4:4)
Supported input resolutions
HDMI input
4K, 1080p/24, 1080p, 1080i, 720p, 480p/576p
• Signals are output from the HDMI OUT jack of this unit to the TV with the
same resolution as the input resolution. When using a TV that supports 4K,
1080p HDMI video signals can also be output as 4K.
Audio Inputs
Digital
OPTICAL (TV)
COAXIAL (CD)
Analog
CD, AUX, PC
Audio Outputs
Analog
ZONE B PRE/LINE OUT
2 SUBWOOFER PRE OUT
Speaker Outputs
FRONT L/R (FRONT L/R terminals supports banana plugs.), CENTER,
SURROUND L/R, HEIGHT L/R or SURROUND BACK L/R or ZONE B L/R
Phones
PHONES (Front, ø 6.3 mm, 1/4")
Others
Setup Mic: 1 (Front)
USB: 1 (Only for supplying power to Streaming media player, 5 V/1.0 A)
