25
Connecting Your Components—Continued
•With the basic connection, you can listen to or record audio from a DVD.
•To enjoy Dolby and DTS listening modes, use connection or . (Use and or and for recording.)
•To enjoy DVD-Audio or SACD playback from a compatible DVD player with an analog multichannel output,
use connection .
• If your DVD player has main left and right outputs and multichannel left and right outputs, be sure to use the
main left and right outputs for connection .
Connecting a DVD player
Connection HT-R430 Signal flow DVD player Picture quality
S VIDEO DVD IN
⇐
S-Video output Better
VIDEO DVD IN
⇐
Composite video output Standard
S VIDEO OUT
IN
DVD
VIDEO OUT
IN
S VIDEO
DVD
VIDEO
Step 1: Video Connection
Choose a connection type ( or
) that matches the DVD player, and then make the connection.
A B
DVD player
A
B
The TV must be connected to
the AV receiver with the same
type of connection.
A
B
Connection HT-R430 Signal flow DVD player
DVD IN FRONT
⇐
Analog audio L/R output
DIGITAL IN COAXIAL
⇐
Digital coaxial output
DIGITAL IN OPTICAL 1
⇐
Digital optical output
DVD IN FRONT, SURROUND,
CENTER, and SUBWOOFER
⇐
Analog multichannel output
OPTICAL
OPTICAL
OUT
AUDIO
OUT
LR
DIGITAL IN
COAXIAL
COAXIAL
OUT
FRONT
SURROUND
DVD
SUB
WOOFER
CENTER
R
L
FRONT
SURR
SUB
WOOFER
CENTER
R
L
L
R
FRONT
DVD
c
Step 2: Audio Connection
Choose a connection type ( , , , or ) that matches your DVD player, and then make the connection.
a b c d
DVD player
a
b
c
d
Connect one
or the other
a
c a b a c
d
a
b
c
d
a
To Next Page
