Onkyo HT-S680 User Manual

55
Specification—Continued
General
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
5.1ch Home Theater Speaker Package
■ Powered Subwoofer (SKW-420)
■ Front Speaker (SKF-330F)
■ Center Speaker (SKC-330C)
■ Surround Speaker (SKM-330S / SKB-330)
Specifications and features are subject to change without
notice.
Power Supply North American: AC 120 V, 60 Hz
Australian: AC 230-240 V, 50 Hz
Power Consumption North American: 5.5 A
Others: 380 W
Stand-by Power
Consumption North American: 0.1 W
Others: 0.5 W
Dimensions
(W
× H × D)
17-1/8" × 5-7/8" × 14-1/2"
345 × 150 × 369 mm
Weight North American: 19.6 lbs. (8.9 kg)
Others: 21.2 lbs. (9.6 kg)
S-Video DVD,VIDEO1,VIDEO2
Composite DVD,VIDEO1,VIDEO2,VIDEO3
S-Video MONITOR,VIDEO1
Composite MONITOR,VIDEO1
Digital Inputs Optical: 1
Coaxial: 1
Analog Inputs DVD(MULTICHANNEL),VIDEO1,
VIDEO2,VIDEO3,TAPE,CD
Multichannel Inputs 6
Analog Outputs TAPE,VIDEO1
Subwoofer Pre Outputs 1
Speaker Outputs SP-A (L, R, C, SL, SR, SB) + SP-B (L, R)
Phones 1
Type: Bass-reflex
Input sensitivity and
impedance: 220 mV/15 kΩ (FL/FR)
Maximum input power: 150 W
Frequency response: 30 Hz–150 Hz
Cabinet capacity: 1.15 cubic feet (32.5 L)
Dimensions
(W
× H × D):
9-1/4"
× 20-3/8" × 16-3/16"
(235
× 518 × 411 mm)
Weight: 28.2 lbs. (12.8 kg)
Drivers unit: 8" (20 cm) Cone (Woofer)
Power supply: North American: AC 120 V, 60 Hz
Australian: AC 230-240 V, 50 Hz
Power consumption: North American: 75 W
Others: 77 W
Other: Auto standby function
Type: 2 Way Bass-reflex
Impedance: 8 Ω
Maximum input power: 100 W
Output sound pressure
level:
83 dB/W/m
Frequency response: 80 Hz–22 kHz
Crossover frequency: 10 kHz
Cabinet capacity: 0.042 cubic feet (1.2 L)
Dimensions
(W
× H × D):
5-13/16" × 7-15/16" × 4"
(148 × 202 × 101 mm)
Weight: 2.0 lbs. (0.9 kg)
Drivers unit: 3-1/8" (8 cm) Cone (Woofer)
3/4" (2 cm) Ceramic (Tweeter)
Terminal: Spring type color coded
Key hole slot: 1
Threaded insert: North American model:
1/4" screw, Depth 5/16"
Other models:
5 mm screw, Depth 8 mm
Grille: Fixed
Other: Magnetic shielding
Type: 2 Way Bass-reflex
Impedance: 8 Ω
Maximum input power: 100 W
Output sound pressure
level:
86 dB/W/m
Frequency response: 80 Hz–22 kHz
Crossover frequency: 10 kHz
Cabinet capacity: 0.081 cubic feet (2.3 L)
Dimensions
(W
× H × D):
14-3/16" × 5" × 5-3/16"
(360 × 127 × 131 mm)
Weight: 3.5 lbs. (1.6 kg)
Drivers unit:
3-1/8" (8 cm) Cone (Woofer)
× 2
3/4" (2 cm) Ceramic (Tweeter)
Terminal: Spring type color coded
Key hole slot: 2
Threaded insert: North American model:
1/4" screw, Depth 5/16"
Other models:
5 mm screw, Depth 8 mm
Grille: Fixed
Other: Magnetic shielding
Type: 2 Way Bass Reflex
Impedance: 8 Ω
Maximum input power: 100 W
Output sound pressure
level:
82 dB/W/m
Frequency response: 80 Hz–22 kHz
Crossover frequency: 10 kHz
Cabinet capacity: 0.042 cubic feet (1.2 L)
Dimensions
(W
× H × D):
5-13/16" × 7-15/16" × 4"
(148
× 202 × 101 mm)
Weight: 1.5 lbs. (0.7 kg)
Drivers unit: 3-1/8" (8 cm) Cone (Woofer)
3/4" (2 cm) Ceramic (Tweeter)
Terminal: Spring type color coded
Key hole slot: 1
Threaded insert: North American model:
1/4" screw, Depth 5/16"
Other models:
5 mm screw, Depth 8 mm
Grille: Fixed
