4
Control Reference Guide
Main unit
INPUT button: Switches the input
source. Each time the button is pressed,
input modes are switched in order of TV#
USB (North American models) #
Bluetooth # ....
* Also, switches the power on/standby. Press
and hold for approximately 3 seconds to place
the device into Standby. Press once to turn the
power on.
VOLUME i/j buttons
SOUND MODE button: Use this button to
select the desired sound mode for the
playback audio. (# P10)
Dolby indicator: Lights when the digital
audio input signal is Dolby Digital.
Left channel speaker
Input source indicator: Lights in
accordance with the input source. The
indicator lights in white for TV, yellow for
USB (North American models), and blue for
Bluetooth.
Status indicators: Displays the sound
mode, volume, and subwoofer level.
Right channel speaker
Bottom of the unit
Subwoofer: Plays sub-bass frequencies.
