Onkyo M-5000R Service Manual

15/37 PAGE
P5506B CRIMP AS CRIMP_PAMC5500 1 20799180UL
P5601B PLUG IMSA-9210B-1-11ZA076-PT1 1 25056677
N
P5602B PLUG IMSA-9210B-1-11ZA076-PT1 1 25056677
N
P6503A CRIMP AS 1.8S-SGM-51T-4:BLK50 1 20799186UL
N
P6504A CRIMP AS 1.8S-SGM-51T-4:BLK50 1 20799186UL
N
P6505A PLUG NPLG-2P645 1 25055689
P6506A PLUG NPLG-2P645 1 25055689
P7507B PLUG NPLG-5P133 1 25055149
P7508B PLUG NPLG-5P133 1 25055149
P7703B PLUG NPLG-2P349 1 25055366
P7704B PLUG NPLG-2P349 1 25055366
P9511A TRM(SCREW) NEJITANSI M3 1 25065425
P9512A TRM(SCREW) NEJITANSI M3 1 25065425
P9513A CRIMP AS 1.8S-TAMAG:RED100 1 2069355102UL
N
P9514A CRIMP AS 1.8S-TAMAG:RED100 1 2069355102UL
N
P9515A TRM(SCREW) NEJITANSI M3 1 25065425
P9516A TRM(SCREW) NEJITANSI M3 1 25065425
P9519A CRIMP AS 1.8S-TAMAG:BROWN100 1 2069355101UL
N
P9520A CRIMP AS 1.8S-TAMAG:BROWN100 1 2069355101UL
N
P9535 RETAINER (BUS-AMP1) 1 27142213
N
P9536 RETAINER (BUS-AMP1) 1 27142213
N
P9539 RETAINER (BUS-AMP1) 1 27142213
N
P9540 RETAINER (BUS-AMP1) 1 27142213
N
RL6587 RELAY NRL-2P5A-DC12-192 1 25065702
RL6588 RELAY NRL-2P5A-DC12-192 1 25065702
M-5000R
PC BOARD PARTS LIS
T
U002 PS-AS BAPS-0559-1 *
1
1B255559-1
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
