M-5000R
SERVICE PROCEDURE - 1
1. Replacing the fuses
2. Safety check out
(U.S.A. model only)
After correcting the original service problem, perform the following safety check before releasing the unit to the customer.
Leakage current Check
Measure the leakage current to a known earth ground (water pipe or conduct etc.) by connecting a leakage current
tester between the earth ground and exposed metal parts of the unit (input/output ground terminals, screw heads or metal overlays etc.).
Plug the power supply cord directly into a 120Vac 60Hz wall socket and turn ON/STANDBY button on.
Any current measured must not exceed 0.5mA.
This symbol located near the fuse indicates that the
fuse used is show operating type, For continued protection against
fire hazard, replace with same type fuse, For fuse rating, refer to
the marking adjacent to the symbol.
Ce symbole indique que le fusible utilise est e lent.
Pour une protection permanente, n'utiliser que des fusibles de meme
type. Ce demier est indique la qu le present symbol est apposre.
REF NO. PART NAME DESCRIPTION PART NO. REMARKS
<Notes>
<MDC> : 120V,Canadian model
<MMP> : 230V,CE(European) country model
<MJJ> : 120 V, Japanese model
F9501 FUSE 1.6A-SE-EAK IECFUSE 1 252073GR <B MPP / S MPP>
F9501 FUSE 5A-UL/T-233 1 252326GR <B MDC / S MJJ>
F9502 FUSE 1.6A-SE-EAK IECFUSE 1 252073GR <B MPP / S MPP>
F9502 FUSE 5A-UL/T-233 1 252326GR <B MDC / S MJJ>
F9503 FUSE 2.5A-SE-EAK FUSE 1 252075GR <B MPP / S MPP>
F9503 FUSE 5A-UL/T-233 1 252326GR <B MDC / S MJJ>
F9504 FUSE 2.5A-SE-EAK FUSE 1 252075GR <B MPP / S MPP>
F9504 FUSE 5A-UL/T-233 1 252326GR <B MDC / S MJJ>
