Onkyo M-5000R Service Manual

19/37 PAGE
Q9508 TR KRA107S 1 2216350R2
Q9521 TR 2SC5171(ONK_Q) 1 2203010
Q9701 TR KRC104S 1 2216210R2
Q9702A TR 2SC5171(ONK_Q) 1 2203010
Q9702B HEAT-SINK HEAT-SINK 1 27160179
Q9702C SCREW 3TTB+8B(3BC) 1 838430088GR
[CHASSIS SCREW]
D2502B HOLDER (LED-LH5-2) 1 27191336
D2503B HOLDER (LED-LH5-2) 1 27191336
D2505B HOLDER (LED-LH5-2) 1 27191336
[TRANS COIL]
T9701 P TRANS NPT-1520JQ 1 2301812A <S MJJ, B MDC>
T9701 P TRANS NPT-1520GQ 1 2301813A <B MPP / S MPP>
[CAPACITOR]
C2501 C-CERA C CK725B1H-103K1 1 332101035R1
C2502 C-CERA C CK725B1H-103K1 1 332101035R1
C2503 C-CERA C CK725F1E-104Z1 1 332161040R1
C2504 C-CERA C CK725B1H-102K1 1 332101025R1
C2506 C-CERA C CK725B1H-102K1 1 332101025R1
C2511 MKT C B32529C0102J289 1 376491024T
C2511 or UMXR C 1HUMXRTF102JE ( 1) 376521024T
C2512 UPZ C 2AUPZTF221JE 1 376332214T
C2513 MKT C B32529C0102J289 1 376491024T
C2513 or UMXR C 1HUMXRTF102JE ( 1) 376521024T
C2514 UPZ C 2AUPZTF221JE 1 376332214T
C2515 C-CERA C CC725CH1H-102J1 1 342101024R1
C2516 C-CERA C CC725CH1H-102J1 1 342101024R1
C2525 UPZ C 2AUPZTF221JE 1 376332214T
C2526 UTSP C CE04W25V-100M(UTSP) 1 397551017T
C2527 UPZ C 2AUPZTF221JE 1 376332214T
C2528 UTSP C CE04W25V-100M(UTSP) 1 397551017T
C2529 UTSP C CE04W25V-100M(UTSP) 1 397551017T
C2530 UTSP C CE04W25V-100M(UTSP) 1 397551017T

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
