Onkyo M-5000R Service Manual

21/37 PAGE
C7739 CERA C CC45SL50V-330J 1 345023304T
C7741 UTSP C CE04W25V-100M(UTSP) 1 397551017T
C7742 UTSP C CE04W25V-100M(UTSP) 1 397551017T
C7743 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C7744 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C9505 UTSP C CE04W50V-10M(UTSP) 1 397581007T
C9507 TF C ECQ-V50V-103J 1 374721034T
C9508 TF C ECQ-V50V-103J 1 374721034T
C9511 IS C RE275V-103M 1 3500196S
!
C9512 IS C RE275V-103M 1 3500196S
!
C9513 IS C RE275V-103M 1 3500196S
!
C9514 IS C RE275V-103M 1 3500196S
!
C9515 TF C ECQ-V50V-103J 1 374721034T
C9516 TF C ECQ-V50V-103J 1 374721034T
C9517 TF C ECQ-V50V-103J 1 374721034T
C9518 TF C ECQ-V50V-103J 1 374721034T
C9519 IS C RE275V-103M 1 3500196S
!
C9520 IS C RE275V-103M 1 3500196S
!
C9525 UTSP C CE04W50V-10M(UTSP) 1 397581007T
C9700 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C9701 UTSP C CE04W50V-10M(UTSP) 1 397581007T
C9703 UTSP C CE04W16V-330M(UTSP) 1 397543317T
C9704 UTSP C CE04W35V-330M(UTSP) 1 397563317T
C9705 TF C ECQ-V50V-104J 1 374721044T
C9706 IS C RE275V-103M 1 3500196S
!
C9707 TF C ECQ-V50V-223J 1 374722234T
C9708 UTSP C CE04W50V-4.7M(UTSP) 1 397580477T
C9709 UTSP C CE04W25V-470M(UTSP) 1 397554717T
C9710 TF C ECQ-V50V-223J 1 374722234T
C9712 IS C RE275V-103M 1 3500196S
!
C9713 IS C RE275V-103M 1 3500196S
!
C9714 UTSP C CE04W25V-100M(UTSP) 1 397551017T
[RESISTOR]

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
