Onkyo M-5000R Service Manual

26/37 PAGE
R9527 THERMISTOR M3R014C 1 4000148
!
R9527A C COVER SB1925A 1 27301216
R9528 THERMISTOR M3R014C 1 4000148
!
R9528A C COVER SB1925A 1 27301216
R9700 METAL O R RS1/2WBJ-330 1 443523314T
R9701 C-CARBON R RN72K1J-562JE 1 435035624R1
R9703 NF CARBON R R25J-1.0K 1 415471024T
R9704 C-CARBON R RN72K1J-104JE 1 435031044R1
R9706 METAL R RNU1/2WCJ-2.2 1 453530224T
R9707 METAL O R RS1/2WBJ-68 1 443526804T
R9708 METAL O R RS1/2WBJ-330 1 443523314T
R9709 FUSE 0.5A-T/UL/SE-125V 1 252379T
!
[SW TRM]
E2507A TRM-423(SCREW) NEJITANSI ST3 1 25060495
E2508A TRM-423(SCREW) NEJITANSI ST3 1 25060495
E2509A TRM-423(SCREW) NEJITANSI ST3 1 25060495
E5501A TRM NTM-1P243(M1699) 1 25060312
E5502A TRM NTM-1P243(M1699) 1 25060312
E5503A TRM NTM-1P243(M1699) 1 25060312
E5504A TRM NTM-1P243(M1699) 1 25060312
E5505A TRM NTM-1P243(M1699) 1 25060312
E5506A TRM NTM-1P243(M1699) 1 25060312
E5507A TRM NTM-1P243(M1699) 1 25060312
E5508A TRM NTM-1P243(M1699) 1 25060312
E9501 TRM-423(SCREW) NEJITANSI ST3 1 25060495
E9502 TRM-423(SCREW) NEJITANSI ST3 1 25060495
E9503 TRM-423(SCREW) NEJITANSI ST3 1 25060495
F9501A FUSE HOL NSCT-1P2031 1 25052133T
F9501B FUSE HOL NSCT-1P2031 1 25052133T
F9502A FUSE HOL NSCT-1P2031 1 25052133T
F9502B FUSE HOL NSCT-1P2031 1 25052133T
F9503A FUSE HOL NSCT-1P2031 1 25052133T
F9503B FUSE HOL NSCT-1P2031 1 25052133T

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
