Onkyo M-5000R Service Manual

M-5000R
EXPLODED VIEWS - 2
M-5000R
A020
A060
A059
A061
A061
A020
P6504B
P6504C
Q6503
A064 x 5pcs
Q6504
Q6511
Q6512
A064
x 5pcs
Q6513
Q6514
Q6515
Q6516
Q6517
Q6519
Q6520
Q6518
Q6521
Q6522
Q6523
Q6524
Q6525
Q6526
Q6526A
Q6527
Q6528
Q6529
Q6530
Q6531
Q6532
Q6533
Q6534
Q6535
Q6536
Q6536A
Q6521A
Q6522A
Q6523A
Q6524A
Q6525A
Q6527A
Q6528A
Q6529A
Q6530A
Q6531A
Q6532A
Q6533A
Q6534A
Q6535A
A018
x 8PCS
A021
x 4PCS
A021
x 4PCS
A054
x 2PCS
A054
x 2PCS
A054
x 2PCS
A054
x 2PCS
A021
x 4PCS
A022
x 8PCS
A022
x 8PCS
A021
x 4PCS
A023
x 4PCS
A023
x 4PCS
A018
x 8PCS
A019
x 4PCS
A019
x 4PCS
U0011
U0010
U0032
U0033
A050
A050

Onkyo M-5000R Specifications

General

Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Input sensitivity	700 mV
Audio output channels	2.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (2 Ohm)	320 W
Dynamic power per channel (3 Ohm)	245 W
Dynamic power per channel (4 Ohm)	196 W
Dynamic power per channel (6 Ohm)	142 W
Dynamic power per channel (8 Ohm)	110 W
RMS power output per channel (8 Ohm)	80 W
XLR out	1
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	280 W
Package weight	27000 g

Weight and Dimensions

Depth	432.5 mm
Width	435 mm
Height	187.5 mm
Weight	23500 g
