Onkyo PA-MC5500 Service Manual

[SW TRM]
F6601 FUSE 20A-UL-250V 1 252304GR
!
F6602 FUSE 20A-UL-250V 1 252304GR
!
F6603 FUSE 20A-UL-250V 1 252304GR
!
F6604 FUSE 20A-UL-250V 1 252304GR
!
F9100 FUSE 6.3A-SE-EAK FUSE 1 252079GR
! <MMP, MMR>
F9100 FUSE 12A-UL-ST6 1 252340GR
! <MDC>
F9100or FUSE 6.3A-SE-TL250V ( 1) 252279GR
! <MMP, MMR>
F9301 FUSE 3.15A-UL/T-233 1 252323GR
!
F9301or FUSE 3.15A-T/UL-ST2 ( 1) 252256GR
!
F9401 FUSE 3.15A-UL/T-233 1 252323GR
!
F9401or FUSE 3.15A-T/UL-ST2 ( 1) 252256GR
!
F9402 FUSE 3.15A-UL/T-233 1 252323GR
!
F9402or FUSE 3.15A-T/UL-ST2 ( 1) 252256GR
!
P061 FAN D09A-12PG13 1 24502328
P062 FAN D09A-12PG13 1 24502328
P9000 AC INLET R301X2PSn 1 25053358
!
P9008 SOCKET AS NSAS-6P1675 1 2009991073UL
[CHASSIS SCREW]
A001 HEAT SINK (5) 1 27160634A
A003 HEAT SINK (4) 1 27160635A
A005 SPACER (PC) 8 27270485
A007 SCREW 3P+6FN(3BC) 8 82143006GR
A009 SCREW 3SMS8W.SW+14B(CU) 18 801634
A011 RETAINER (HS-2) 2 27141530A
A013 SCREW 3TTB+8B(3CM)SR 4 801637
A017 RETAINER (HS-C)B 1 27142161A
A019 SCREW 3TTB+8B(3CM)SR 8 801637
A021 RETAINER (HS-L)B 1 27142162
A023 SCREW 3TTB+8B(3CM)SR 4 801637
A025 HOLDER (ｸﾗﾝﾌﾟ) UA-0 1 27190432
A027 HOLDER WS-4NS 1 27191207
A029 RETAINER (HS-R)B 1 27142163
A031 SCREW 3TTB+8B(3CM)SR 4 801637
A033 HOLDER (ｸﾗﾝﾌﾟ) UA-0 1 27190432
A037 SCREW 3TTB+8B(3CM)SR 4 801637
A039 SCREW 3TTB+8B(3CM)SR 9 801637
A041 HEAT SINK(S) 240 1 27160608
A043 SCREW 3TTB+8B(3CM)SR 3 801637
