Onkyo PA-MC5500 Service Manual

PARTS LIST PA-MC5500
<MDC>:
Canadian model
NOTE:
<MMP>:
European model
THE COMPONENTS IDENTIFIED BY MARK ! ARE
<MMR>:
Chaina model CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE ONLY WITH PART NUMBER SPECIFIED.
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
Q6050 TR TTC0002(Q)TO3PL 1 2204150
Q6050A ISO SHEET ISO SHEET(NR5007_4CH) 1 223052
Q6051 TR TTC0002(Q)TO3PL 1 2204150
Q6051A ISO SHEET ISO SHEET(NR5007_5CH) 1 223051
Q6052 TR TTC0002(Q)TO3PL 1 2204150
Q6053 TR TTC0002(Q)TO3PL 1 2204150
Q6054 TR TTC0002(Q)TO3PL 1 2204150
Q6055 TR TTC0002(Q)TO3PL 1 2204150
Q6056 TR TTC0002(Q)TO3PL 1 2204150
Q6057 TR TTC0002(Q)TO3PL 1 2204150
Q6058 TR TTC0002(Q)TO3PL 1 2204150
Q6060 TR TTA0002(Q)TO3PL 1 2204140
Q6060A ISO SHEET ISO SHEET(NR5007_4CH) 1 223052
Q6061 TR TTA0002(Q)TO3PL 1 2204140
Q6061A ISO SHEET ISO SHEET(NR5007_5CH) 1 223051
Q6062 TR TTA0002(Q)TO3PL 1 2204140
Q6063 TR TTA0002(Q)TO3PL 1 2204140
Q6064 TR TTA0002(Q)TO3PL 1 2204140
Q6065 TR TTA0002(Q)TO3PL 1 2204140
Q6066 TR TTA0002(Q)TO3PL 1 2204140
Q6067 TR TTA0002(Q)TO3PL 1 2204140
Q6068 TR TTA0002(Q)TO3PL 1 2204140
[TRANS COIL]
T901 P TRANS NPT-1554D
1 2301898
! <MDC>
T901 P TRANS NPT-1554M 1 2301899
! <MMP, MMR>
T902 P TRANS NPT-1582D 1 2301955
! <MDC>
T902 P TRANS NPT-1582M 1 2301956
! <MMP, MMR>
