Onkyo PA-MC5500 Service Manual

[PACKING]
A701 SHEET T0.515*1300*900 1 29096066
A702 SHEET T0.5x600x500 1 29096097
A703 POLY BAG w500xd650 1 29100249
A705 TAPE (SEROHAN)NITTO NO.29 1 29110149
A711 PAD (AS-PAMC) 1 29092494A
N
A731 CARTON PAMC5500 1 29055089A
N
A733 SHEET (ACC) 1 29096104
A735 STAPLE FUKAN-BARI(1000KO) 4 282321
A737 PP TAPE W50 SBT-70 1 29110200
A751A UPC LABEL PAMC5500DC { 1} 29391099
N <MDC>
A751A EAN LABEL PAMC5500MP { 1} 29391100
N <MMP>
A751A EAN LABEL PAMC5500MR { 1} 29391101
N <MMR>
A757 LABEL (CARTON) 1 29390944
<MMR>
A759 LABEL (CHINA-5500) 1 29391098
N <MMR>
[ACCESSARY]
A763 LABEL (SPCABLE)2009 1 29390881
A765 WRNTY CARD (ONKYO) 1 29365135
<MDC>
A765 WRNTY CARD (ONKYO-CH) 1 29365098B
<MMR>
A769 INST SHEET CHINA ROHS 1 29355616A
<MMR>
A771 INST SHEET WEEE 1 29355537A
<MMP>
A775 POLY BAG w250xd350 1 29100250A
A777 POLY BAG w250xd350 1 29100250A
A781 TAPE (SEROHAN)NITTO NO.29 1 29110149
A783 TAPE (SEROHAN)NITTO NO.29 1 29110149
A851 INS MANUAL
En(PA-MC5500) 1 29400190
N
A853 INS MANUAL U2FrDe(PA-MC5500) 1 29400192A
N <MDC, MMP>
A854 INS MANUAL U4ItDeNISv(PA-MC5500) 1 29400193
N <MMP>
A855 INS MANUAL Cs(PA-MC5500) 1 29400194A
N <MMR>
P901 AC CORD AS-CEE-3 1 253298VOL
! <MMP>
P901 AC CORD AS-UC-2 1 253301VOL
! <MDC>
P901 AC CORD AS-CCC 1 253358VOL
! <MMR>
P902 CORD AS 3.5 MINI PLUG 1 2010431
PRINTED CIRCUIT PARTS LIST
PA-MC5500
U001 U0010 ~ U0014 1B234580-1C N
U0010 AMP-4 POWER SUPPLY PCB AS BAAF-0180-1C 1B2345180-1C N
U0011 AMP DIODE PCB AS BAPS-0181-1C 1B2345181-1C N

Onkyo PA-MC5500 Specifications

General

Brand	Onkyo
Model	PA-MC5500
Category	Amplifier
Language	English
