A295 SCREW 3TTB+8B(3BC) 11 838430088GR
A298 SPACER (φ6‐3‐1.0) 1 27270492
A303 BUSHING BUSHING 2 28170040
A304 BUSHING CE-016 L=40 1 28170102
A305 BUSHING CE-016 L=70 1 28170103
P6800 P RIVET JB-407A-C 18 880052
<MMP, MMR>
[CABINET]
A301 F BRACKET (PAMC5500) 1 27111572A
N
A311 KNOB (STBY)AS5007 1 28326703A
A321 SCREW 3TTB+8B(3CM)SR 8 801637
A325 SCREW 3TTB+8B(3BC) 3 838430088GR
A327 SCREW 3TTB+8B(3BC) 3 838430088GR
A331 F PANEL (PAMC5500(B)) 1 27213353
N
A333 BADGE BADGE 1 28135244
A335 FACET (AMP) 1 28200046A
N
A337 FACET --- 1 28198905
A351 KNOB (POWER)AS 1 28326814
A353 SCREW 3P+6FN(3BC) 2 82143006GR
A355 SCREW 3TTB+8B(3CM)SR 2 801637
A357 TAPE Scotch#810W18 1 29110208
A359 CUSHION (BUTYL) 1 28141748
A551 COVER (B) (Bent) 1 28210040A
A551 COVER (B) (Not Bent) 1 28210040AZ
A553 LABEL (COVER) 1 29364123
A555 SCREW 4TTB+8C(3BC) 6 838440089GR
A557 SCREW 3TTB+8B(3BC) 3 838430088GR
A559 TAPE TAPE(CLOTH-8U) 1
29110082
A561 LABEL HOOKUP-ONKYO 1 29363194
<MDC>
[TUNER UNIT]
U001 U0010 ~ U0014 1 1B234580-1C N
U0010 AMP-4 POWER SUPPLY PCB AS BAAF-0180-1C 1 1B2345180-1C
N
U0011 AMP DIODE PCB AS BAPS-0181-1C 1 1B2345181-1C
N
U0012 AMP RELAY PCB AS BAPS-0182-1C 1 1B2345182-1C
N
U0013 THERMAL SENSOR-1 PCB AS BAETC-0183-1C 1 1B2345183-1C
N
U0014 THERMAL SENSOR-2 PCB AS BAETC-0184-1C 1 1B2345184-1C
N
U002 U0020 + U0021 1 1B234591-1A N
U0020 AMP-2 (Final stage) PCB AS BAAMP-0191-1A 1 1B2345191-1A
N
U0021 AMP-3 (Final stage) PCB AS BAAMP-0192-1A 1 1B2345192-1A
N
U003 U0030 ~ U0038 1 1B234526-1A N
