S7700 PUSH SW NPS-111-S681 1 25035718T
S7701 PUSH SW NPS-111-S681 1 25035718T
S9000 P SW NPS-111-L687P(TV-5) 1 25035724
U006 U00600 ~ U00611 1B234507-1A N
U00600 CPU PCB AS BADG-0307-1A 1B2345307-1A N
U00601 HOLDER PCB AS BAMEC-0308-1A 1B2345308-1A N
U00602 INPUT TERMINAL PCB AS BATRM-0310-1A 1B2345310-1A N
U00603 INPUT TERMINAL PCB AS BATRM-0311-1A 1B2345311-1A N
U00604 INPUT TERMINAL PCB AS BATRM-0312-1A 1B2345312-1A N
U00605 INPUT TERMINAL PCB AS BATRM-0313-1A 1B2345313-1A N
U00606 INPUT TERMINAL PCB AS BATRM-0314-1A 1B2345314-1A N
U00607 INPUT TERMINAL PCB AS BATRM-0315-1A 1B2345315-1A N
U00608 INPUT TERMINAL PCB AS BATRM-0316-1A 1B2345316-1A N
U00609 INPUT TERMINAL PCB AS BATRM-0317-1A 1B2345317-1A N
U00610 INPUT TERMINAL PCB AS BATRM-0318-1A 1B2345318-1A N
U00611 AUTO POWER SAVE SW PCB AS BATRM-0319-1A 1B2345319-1A N
CIRCUIT. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D7001 C-DIODE 1SS352 1 223234R2
D7002 C-DIODE 1SS352 1 223234R2
D7004 C-DIODE 1SS352 1 223234R2
D7005 C-DIODE 1SS352 1 223234R2
D7006 ZENER D UDZS5.1B 1 224550510R2
D7010 C-DIODE 1SS352 1 223234R2
D7011 ZENER D UDZS5.1B 1 224550510R2
D7500 C-DIODE 1SS355 1 223269R2
D7501 C-DIODE 1SS355 1 223269R2
D7502 C-DIODE 1SS355
1 223269R2
D7503 C-DIODE 1SS355 1 223269R2
D7504 C-DIODE 1SS355 1 223269R2
D7505 C-DIODE 1SS355 1 223269R2
D7506 C-DIODE 1SS355 1 223269R2
D7507 C-DIODE 1SS355 1 223269R2
D7508 C-DIODE 1SS355 1 223269R2
Q7000 IC (Main CPU) R5F212A7SNFA (03430) 1 222W0099R303430M
Q7001 IC XC6202P502FR 1 22242331R2
