Onkyo SWA-155X User Manual

KRC102S 2216190R2 O O O O
Q981
TRANSISTO
R
2SK365-G
R
2212445 O O O O
Q983
TRANSISTO
R
2SA950-
Y
2211504 O O O O
Q984
TRANSISTO
R
2SC1815-GR o
r
2211255 o
r
OOOO
KTC3198-Gr 2215985 O O O O
R501-R506
C-CARBON
R
RN72K1J-331JE 435033314R1
OOOO
R509,R585
R588,R972
C-CARBON R RN72K1J-000JE 435030004R1 O O O O
R541-R546
R551-R556
METAL O R RS1/2WBJ-10 443521004 O O O O
R571-R576
R981,R989
C-CARBON R RN72K1J-224JE 435032244R1 O O O O
R586,R590
C-CARBON R
RN72K1J-103JE 435031034R1
OOOO
R587,R598
R977,R986
C-CARBON R RN72K1J-473JE 435034734R1 O O O O
R589
C-CARBON
R
RN72K1J-101JE 435031014R1
OOOO
R591
C-CARBON
R
RN72K1J-562JE 435035624R1
OOOO
R593,R594
R595,R596
C-CARBON R RN72K1J-102JE 435031024R1 O O O O
R599
THERMISTO
R
PTH9M04BC222TS2 F333 4000150
OOOO
R971
METAL O R
RS1/2WBJ-820 443528214
OOOO
R978
C-CARBON
R
RN72K1J-222JE 435032224R1
OOOO
R979
METAL O R
RS1/2WBJ-39 443523904
OOOO
R982
C-CARBON
R
RN72K1J-105JE 435031054R1
OOOO
R983,R985
C-CARBON
R
RN72K1J-183JE 435031834R1
OOOO
R984
C-CARBON
R
RN72K1J-332JE 435033324R1
OOOO
R988
C-CARBON
R
RN72K1J-471JE 435034714R1
OOOO
RL901 RELAY NRL-1P5A-DC9-150 25065601 O O O O
A1 HEAT SINK 27160506 O O O O
A2 BRACKET(LR) 27130881 O O O O
A3 BRACKET(BT) 27130882 O O O O
