Onkyo SWA-155X User Manual

A4 CUSHION 10x10xt0.5 28141464 O O O O
A5 RETAINER AC CORD 27141822 O O O O
A6 SCREW 3TTB+8B 838130088 O O O O
A7 SCREW 3SMS8W.SW+14B(BC) 801433 O O O O
A8 SCREW 3TTB+8B(BC) 838430088 O O O O
A9 SCREW 5TTB+10B(BC) 838450108 O O O O
A10 SCREW 4TTC+10C(BC) 830440109 O O O O
A11 NUT FWN4*10FN 86414010 O O O O
A12 REAR PANEL - O O - -
---OO
A13 BUSHING S-RELIEF #2271 27300750 O O O O
A14 SERIAL LABEL - O O O O
A15 WIRE TIE
BINDER(CLAMPER) U
L
260208 O O O O
S1 CABINET AS
BOX + ACOUSTIC SPONG + BUTYL + LED
CORD AS + SP CORD AS
505-1HTP-DR7 O O O O
S10 SPEAKER UNIT for SUBWOOFER W16146B O O O O
S11 PACKING 130x35x1t 429-NS-323A O O O O
S2 BOTTOM BOARD AS
BOTTOM BOARD + DISK BOARD φ80 +
DISK BOARD φ108 + ED BOARD +
SPONGE
516-HTP-DR7 O O O O
S3 WOOD SCREW BIND HEAD 4x20(BC) TAPPING(A) 300-B8402000 O O O O
S4 WOOD SCREW BIND HEAD 4x50(BC) TAPPING(A) 300-B8405000 O O O O
S5 WOOD SCREW BIND HEAD 4x16(BC) TAPPING(A) 300-B8401600 O O O O
S6 RUBBER WASHER
φ7xφ3.9x1t
430-NS-291 O O O O
S7 PLATE PVC 1t BLACK 410-NS-323 O O O O
S8 COVER 400-1CNS-323 O O O O
S9 FRONT PLATE W/PRINTED 410-FSWA-155X O O O O
U1
PWB
NCAF-7512
- OOOO
U3
PWB
NCETC-7513
- OOOO
U4
PWB
NCETC-7514
- OOOO
U5
PWB
NCPS-7515
- OOOO
F901 FUSE 2.5A-UL/T-237 252160 O O - -
800mA-SE-EAK-FUS
E
252069
--OO

Onkyo SWA-155X Specifications

General

Brand	Onkyo
Model	SWA-155X
Category	Subwoofer
Language	English
