Onkyo TX-NR1010 User Manual

Safety Information and Introduction
En-7
Features
Amplifier
• 140 Watts/Channel @ 8 ohms (FTC)
• 200 Watts/Channel @ 6 ohms (IEC)
• WRAT–Wide Range Amplifier Technology
(5 Hz to 100 kHz bandwidth)
• Linear Optimum Gain Volume Circuitry
• H.C.P.S. (High Current Power Supply) Massive High
Power Transformer
• 3 Stage Inverted Darlington Amplifier Design
Processing
• THX Ultra2 Plus Certified
• Incorporates Qdeo™ technology for HDMI Video
Upscaling (to 4K Compatible)
• HQV
®
-Vida Video Processing with 1080p Video
upscaling of All Video Sources via HDMI
• HDMI (Audio Return Channel, 3D, DeepColor,
x.v.Color, Lip Sync, DTS-HD Master Audio, DTS-HD
High Resolution Audio, Dolby TrueHD, Dolby Digital
Plus, DSD and Multi-CH PCM)
• Dolby TrueHD and DTS-HD Master Audio
• Dolby Pro Logic IIz and Audyssey DSX
®
• DTS Neo:X
• Non-Scaling Configuration
• A-Form Listening Mode Memory
•Direct Mode
• Pure Audio Mode
• Music Optimizer for Compressed Digital Music files
• 192 kHz/24-bit D/A Converters
• Powerful and Highly Accurate 32-bit Processing DSP
• Jitter Cleaning Circuit Technology
• Digital Processing Crossover Network
• DSD Direct for Super Audio CD
Connections
• 9 HDMI Inputs (1 on front panel) and 2 Outputs
• Zone 2 HDMI Output
• Onkyo p for System Control
• 6 Digital Inputs (3 Optical/3 Coaxial)
• Component Video Switching (2 Inputs/1 Output)
• Banana Plug-Compatible Speaker Posts
*
In Europe, using banana plugs to connect speakers to an audio
amplifier is prohibited.
• Powered Zone 2/3
• Bi-Amping Capability for FL/FR with FHL/FHR
• Analog RGB Video Input (D-sub 15) for PC
• 2 Independent Subwoofer Pre Outs
• (North American models) HD Radio Capability
• Internet Radio Connectivity
• Network Capability for Streaming Audio Files
• 2 USB Inputs (Front/Rear) for Memory Devices and
iPod
®
/iPhone
®
models
*
Only the front-panel USB input is compatible with
iPod/iPhone.
• MHL-Enabled AUX Front Input
Miscellaneous
• 40 FM/AM Presets
• Dolby Volume
• Audyssey MultEQ
®
XT32 to correct room acoustic
problems
• Audyssey Dynamic EQ
®
for loudness correction
• Audyssey Dynamic Volume
®
to maintain optimal
listening level and dynamic range
• Crossover Adjustment
(40/45/50/55/60/70/80/90/100/110/120/130/150/200 Hz)
• A/V Sync Control Function (up to 800 ms)
• Auto Standby Function
• On-Screen Display via HDMI
• Preprogrammed (with onscreen display setup)
RI-Compatible Learning Remote with 4 Activities and
Mode-Key LEDs
• ISF (Imaging Science Foundation) Video Calibration
• VLSC (Vector Linear Shaping Circuitry) for All
Channels

Onkyo TX-NR1010 Specifications

General

Impedance	75 Ω
Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.05 %
Dynamic power per channel (3 Ohm)	320 W
Dynamic power per channel (4 Ohm)	270 W
Dynamic power per channel (8 Ohm)	160 W
Power output per channel (1KHz@6 Ohm)	200 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	9
Line-in	Yes
Remote (IR) input	1
Composite video in	5
Digital audio optical in	3
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
12V trigger ports quantity	12
Audio formats supported	AAC, FLAC, LPCM, MP3, OGG, WAV, WMA
Wi-Fi	No
RDS features	PS, PTY, RT, TP
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic, DTS Neo:6
Apple docking compatibility	Not supported
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.15 W
Power consumption (typical)	850 W
Package depth	594 mm
Package width	610 mm
Package height	337 mm
Card reader integrated	-

Weight and Dimensions

Depth	463.5 mm
Width	435 mm
Height	198.5 mm
Weight	23000 g
