General Specications
 Amplier Section
Rated Output Power (FTC) (North American)
With 8 ohm loads, both channels driven, from 20-20,000 Hz; rated 120
watts per channel minimum RMS power, with no more than 0.08% total
harmonic distortion from 250 milliwatts to rated output.
Rated Output Power (IEC) (Others)
9 ch × 180 W at 6 ohms, 1 kHz, 1 ch driven of 1% THD
Maximum E󰀨ective Output Power (North American)
250 W at 6 ohms, 1 kHz, 1 ch driven of 10% THD
Maximum E󰀨ective Output Power (JEITA)
9 ch × 215 W at 6 ohms, 1 kHz, 1 ch driven of 10% THD (Asian and
Australian)
Dynamic Power (*)
* IEC60268-Short-term maximum output power
250 W (3 Ω, Front)
220 W (4 Ω, Front)
130 W (8 Ω, Front)
THD+N (Total Harmonic Distortion+Noise)
0.08% (20 Hz - 20,000 Hz, half power)
Input Sensitivity and Impedance
200 mV/47 kΩ (LINE (RCA))
3.5 mV/47 kΩ (PHONO MM)
Rated RCA Output Level and Impedance
1 V/470 Ω (PRE OUT)
1 V/470 Ω (SUBWOOFER PRE OUT)
1V, 200 mV/470 Ω (ZONE 2 PRE/LINE OUT)
1V, 200 mV/470 Ω (ZONE 3 PRE/LINE OUT)
Phono Maximum Input Signal Voltage
70 mV (MM 1 kHz 0.5%)
Frequency Response
5 Hz - 100 kHz/+1 dB, –3 dB (Direct/Pure Audio)
Tone Control Characteristics (MAIN)
±10 dB, 20 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Tone Control Characteristics (ZONE 2)
±10 dB, 100 Hz (BASS)
±10 dB, 10 kHz (TREBLE)
Signal to Noise Ratio
106 dB (IHF-A, LINE IN, SP OUT)
80 dB (IHF-A, PHONO IN, SP OUT)
Speaker Impedance
4 Ω - 16 Ω
Headphone Rated Output
85 mW + 85 mW (32 Ω, 1 kHz, 10% THD)
Supported impedance of Headphones
8 Ω - 600 Ω
Headphones Frequency Response
10 Hz - 100 kHz
 Video Section
Signal level
1 Vp-p/75 Ω (Composite Video)
1 Vp-p/75 Ω (Component Video Y)
0.7 Vp-p/75 Ω (Component Video Pb/Pr)
Maximum resolution supported by component video
480i/576i
 Tuner Section
FM Tuning Frequency Range
87.5 MHz - 107.9 MHz (North American)
87.5 MHz - 108.0 MHz, RDS (Others)
50dB quieting sensitivity (FM MONO)
1.56 μV, 15.0 dBf (IHF, 1kHz, 100% MOD)
AM Tuning Frequency Range
530 kHz - 1710 kHz (North American)
522/530 kHz - 1611/1710 kHz (Others)
Preset Channel
40
