 7.1.4 Channel System
A 7.1.4 Channel System is a speaker layout combining 2 sets of the height speakers, 1 set of left and right at the front and 1 set of left and right at the rear, to the basic
7.1 Channel System ( p15). By installing the height speakers, when the input format is Dolby Atmos, you can select the Dolby Atmos listening mode which realizes
the most up-to-date 3D sound including overhead sound. Combination of 2 height speakers can be selected from following.
❏ Combination example when Top Front
Speakers are used at the front ( p33)
❏ Combination example when Top Middle
Speakers are used at the front ( p35)
❏ Combination example when Front High
Speakers are used at the front ( p36)
❏ Combination example when Dolby Enabled
Speakers (Front) are used at the front
( p38)
